Hot sale battery auto cutter cutting machine
Should you need recycling lead battery,pls contact me today to get one battery cutter.This battery cutter can be used to cut the lead batteriy into small size and empty the acid liquid. After cutting,the battery case can be removed easilyl from plate and grid.plate and grid can be easily shredded at next step.Yoiu can use this battery cutter to cut the lead battery before you feed into the granulator or grind if you want to separate the grid.Spongy lead and plastics.Should you also need whole line to break and separate the lead batteriy,pls contact me for the catalogue of lead battery recycling plant. For video and high definition photos of battery cutter and lead battery recycle line, pls also contact me now.
Battery cutting speed:1-2ton per hour
60-100pcs/hr
Waste battery recycling Video
https://youtu.be/hFMvITsmJpU Battery cutting video
https://youtu.be/4Ejuq1bsb_g Battery breaking and separation
(1), product name : battery auto cutter cutting machine
(2), the technical parameters:
1. The motor power: 7.5 K
2. Oil cylinder diameter: 150
3. Common working pressure: 16~20 MPA
4. Type: horizontal shear, manual or automatic control.
(3), the main material instructions
1. The blade: 9 SI CR hardness: HRC 56-62
2. The body and the rest of the frame for ordinary carbon steel
(4) related instructions
1. The motor Y132M-4 7.5 KW
2. Piston pump 40 YCY 14-1 B
3. Oil seal 1 set
(5) the scope of supply
One main machine , one conveying frame, one hydraulic station , one motor and one control box;
(6) the vulnerability parts of machine
Oil seal: UM150 X 130 X15 2unit ; UM100 X 115 X 12 2unit;
J 100 X 110 X 6-8 1unit.
O circle: 5 X 150 a 5 X 75 2unit.
1 how long is the product warranty period ?
A: the product warranty period is 12 months since buying.
2. I am a foreign customers, if the machine works wrong, how will you sort it out ?
A: We can send professional engineers abroad, after receiving your request, we will solve your problems at first time.if Asian customers,we will setup new factory in South Korea.It will be much sooner for onsite mainteance.
3. how much is MOQ of your machine?
A:1 set
In order to make your business efficiency, please tell us following information:
2. Capacity (per hour or day)?
3. Final Output size ?
4. Voltage in your country(price here based on 380v,50hz,3phase )?
Contact person: Ms.Ying
E-mail: sales5 (at)
