Home > Electrical & Electronics > Connector & Terminals > Wire to Wire Connector > 2.54mm (.100") Pitch PCB and Wire Connectors

2.54mm (.100") Pitch PCB and Wire Connectors

Name: 2.54mm (.100") Pitch PCB and Wire Connectors
Brand: NANGUDI
SKU: 111413673
Availability: InStock

2.54mm (.100") Pitch PCB and Wire Connectors thumbnail-1

2.54mm (.100") Pitch PCB and Wire Connectors photo-1

US$ 0.013 - 0.23 MOQ: 500 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

NANGUDI

Model Number:

WTB-10254 series

Contact Supplier Request Quote Chat Now

Dongguan Nangudi Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HK

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name NANGUDI

Model Number WTB-10254 series

Type Other, wire-to-board

Application Other, Electronics, Automobile, home appliance

Gender Other, male-female

Specifications

Subminiature in size and pitch
Positive locking between housing and header which is easy to handle and secure

Many applications require a wire-to-board connector that is sub-miniature in size but offers many of the attributes of connectors larger in size.

The GVH Series wire-to-board connectors are on a 1.25mm (.049”) pitch, molded in a 94V0 PBT, SMT compatible, polarized and have a secure positive locking feature including an audible click and tactile feedback, when mated.

The series has an operating temperature range of -25 C to +85C including temperature rise when applying an electrical current.

The series is offered in 2~15 pin sizes.

crimp style wire-to-board connector series

single row crimp style wire-to-board connector series is available in 2 through 15 holes.

The series is rated at 1.0 amp AC/DC using a 26AWG wire,

has a rating of 50 volts AC/DC and

operates in a temperature range of -25 degrees centigrade to +85 degrees centigrade.

The GVH single row crimp style wire-to-board contacts will accommodate a wire range of 30 to 26 AWG . Contacts are tin plated brass providing for a very reliable contact interface and cost effective solution.
