100w Constant Voltage Led Driver IP67 24v Led Transformator 100w

Name: 100w Constant Voltage Led Driver IP67 24v Led Transformator 100w
Brand: SANPU
SKU: 111383703
Availability: InStock

US$ 5 - 25 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SANPU

Model Number:

LP100-W1V

Shenzhen Sanpu Intelligent Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SANPU

Model Number LP100-W1V

Output Power Other, 100W

Output Type Single

Input Voltage Other, 85~264VAC

Output Voltage 24V etc

Output Frequency 47~63hz

Output Current 0~8.5a

Specifications

100w constant voltage led driver
nstant voltage
2.two years warranty
3.CE ROHS approved

100w constant voltage led driver

Features

1.universal AC input

2.Protections: shortcuit, over load, over temp, over voltage

3.Build-in EMI filter with tiny ripple

4.100%full load burn-in test

5.Small volume high-efficiency

6.Conform to EN60950 GB4943 UL60950 safety standards

7.Conform to GB9254, EN55022,EMC standards

Parameter

AC input voltage range	85~264VAC
Input current	1.8A/110V, 1A/230V
Input frequency	47~63Hz
Inrush current	cold start, 40A/230V
Input leakage current	< 1mA/240VAC
Output voltage adjust range	±10%rated output voltage
Output overload protection	115-~135%, hiccup mode, auto recovery
Output over voltage protection	115-~135%, cut off the out put, auto recovery
Withstand voltage	I/P-O/P: 1.5KVAC/1min, I/P-F/G: 1.5KVAC/1min, O/P-F/G: 0.5KVAC/1min
Operating temperature	-20°C ~+60°C
Operating humidity	20%~90%
packing	40pcs/24kg
size	19252.837
weight	0.6kg/pcs
