ce rohs approved 12v 20w waterproof led driver
- 50000 Piece / Pieces per Month
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- New Weidmuller power supply 639B0115H02, York Kunteng control system switch power supply 639B0115H03
- New Weidmuller Power Switching Power Supply 639B0115H01
- ME Series Modules High Stability High Voltage Power Supply for Microchannel Plates
- MMC Series DC High Stability Voltage Power Supply for Microchannel Plates (100V-600V,0.1W)
- Brand new power box 640C0022G01 York control system motherboard power supply GLC75D-CVG
- Power Supplies TVD1.3-15-03 Original Stock
Product Details
Place of Origin: | Guangdong, China | Brand Name: | sanpu | Model Number: | LP20-W1V |
Output Power: | Other, 20W | Output Type: | Single | Input Voltage: | Other, 85~264vac |
Output Voltage: | 24v etc. | Output Frequency: | 47~63Hz | Output Current: | 0~0.83a |
Product Description
Specifications
12v 20w waterproof led driver1.can install at outdoor
2.universal AC input
3.100%burn-in test
4.long lifespan
12v 20w waterproof led driver
Products Features
1.Universal AC input
2.Protections: short circuit, over load, over temp,
3.Build-in EMI filter with tiny ripple
4.100%full load burn-in test
5.Small volume high-efficiency
6.Conform to EN60950 GB4943 UL60950 safety standards
Conform to GB9254, EN55022,EMC standards
Paramater
AC input voltage range | 85~264VAC |
Input current | 0.5A/110V, 0.28A/230V |
Input frequency | 47~63Hz |
Inrush current | cold start, 30A/230V |
Input leakage current | < 0.5mA/240VAC |
Output overload protection | 115-~135%, hiccup mode, auto recovery |
Output over voltage protection | |
Withstand voltage | I/P-O/P: 1.5KVAC/1min, I/P-F/G: 1.5KVAC/1min, O/P-F/G: 0.5KVAC/1min |
Operating temperature | -20°C ~+60°C |
Operating humidity | 20%~90% |
packing | 100pcs/15kg |
size | 145*30*22mm |
weight | 0.15kg/pcs |
Water level | IP67 |
model | outpot voltage | output current | rated power | error | efficiency |
LP20W-W1V12 | 12V | 0~1.7A | 20W | ± 1% | 85% |
LP20W-W1V15 | 15V | 0~1.4A | 20W | ± 1% | 86% |
LP20W-W1V24 | 24V | 0~0.8A | 20W | ± 1% | 88% |
IF above specification are not what you demand, please contact us, we are an 8 years professional power supply factory, have various models, also can customize to you!
