Help CenterHigh Carbon Galfan Steel Wire
US$ 600 - 900
MOQ: 1 Ton
Key Specifications
Get Latest Price
Standard:
ASTM, EN, JIS
Grade:
Other, SWRCH72A
Wire Gauge:
2.5mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stainless Steel Cold Heading WireUS$ 20 - 50MOQ: 500 Kilograms -
Stainless Steel Redrawing WireUS$ 10 - 50MOQ: 100 Kilograms
-
Brass Coated Steel Wire for BrushUS$ 0.9 - 1.5MOQ: 3000 Pieces
-
Hot Sale Brass Coated Steel Wire for HoseNegotiableMOQ: 1 Ton
-
Brass Coated Steel Saw WireUS$ 1,800 - 3,600MOQ: 1 Ton
Standard
ASTM, EN, JIS
Grade
Other, SWRCH72A
Wire Gauge
2.5mm
Length
20000meters
Application
wire mesh
Certification
SGS
C Content (%)
0.70
Si Content (%)
0.35
Place of Origin
China
Brand Name
ausight
Model Number
Diameter 2.5mm
high carbon galfan steel wire
Product Description
Wire Diameter :1.5-5.0mm
Weight of Zinc coating: 450g/m2 Max
AL.Zn.Content: 5% AL. 95% ZINC and 10% AL. 90%ZINC
Tensile strength: 350-800N/mm2(Low carbon)&800-1500N/mm2(Middle/High Carbon)
Standard: EN10244-2 ASTMB802M ASTMB-803
Packing:200-800kgs/coil
Wire Rod: Q195, Q235, SAE1006/1008 45# 65# etc.(Material Raw)
| Strength rank | Nominal diameter(mm) | Tensile strength Mpa>= | Stress by 1% elongae Mpa>= | Elongation L=250mm>= | Number of twists time/360° |
| Ordinary strength | >1.24-2.25 | 1340 | 1170 | 3.0 | 16 |
| >2.25-2.75 | 1310 | 1140 | 3.0 | 16 | |
|
>2.75-3.00 |
1310 |
1140 |
3.5 |
16 |
|
>3.00-3.50 |
1290 |
1100 |
3.5 |
14 |
>3.50-4.25 |
1290 |
1100 |
4.0 |
12 |
|
|
>4.25-4.75 |
1290 |
1100 |
4.0 |
12 |
>4.75-5.50 |
1290 |
1100 |
4.0 |
12 | |
High strength |
>1.24-2.25 |
1450 |
1310 |
2.5 |
16 |
>2.25-2.75 |
1410 |
1280 |
2.5 |
16 |
|
|
>2.75-3.00 |
1410 |
1280 |
3.0 |
16 |
>3.00-3.50 |
1410 |
1240 |
3.0 |
14 |
|
>3.50-4.25 |
1380 |
1170 |
3.0 |
12 |
|
>4.25-4.75 |
1380 |
1170 |
3.0 |
12 |
|
>4.75-5.50 |
1380 |
1170 |
3.0 |
12 |
