STA U type 1500C Silicon Carbide heating elements rod
specification of silicon carbide heating rod
SiC heating element can usually make use for which furnace temperature from 600C~1600C. Directly it can be used in an air atmosphere without any protection atmosphere. It is extensively used in the fields of metallurgy, ceramic, glass, machinery analysis test, semiconductor and so on .
1. professional manufacturer
2. High-density, high-purity
3. Top quality and long working life
4. Lower price
the dimensions of SiC heater
|
Dia(OD) (mm) |
Length of hot zone(HZ)(mm) |
Length of cold zone(CZ)(mm) |
Overall Length(OL)(mm) |
Range of Resistance(Ω) (ohms) |
8 |
100-300 |
60-200 |
240-700 |
2.1-8.6 |
12 |
100-400 |
100-350 |
300-1100 |
0.8-5.8 |
14 |
100-500 |
150-350 |
400-1200 |
0.7-5.6 |
16 |
200-600 |
200-350 |
600-1300 |
0.7-4.4 |
18 |
200-800 |
200-400 |
600-1600 |
0.7-5.8 |
20 |
200-800 |
250-600 |
700-2000 |
0.6-6.0 |
25 |
200-1200 |
250-700 |
700-2600 |
0.4-5.0 |
30 |
300-2000 |
250-800 |
800-3600 |
0.4-4.0 |
35 |
400-2000 |
250-800 |
900-3600 |
0.5-3.6 |
40 |
500-2700 |
250-800 |
1000-4300 |
0.5-3.4 |
45 |
500-3000 |
250-750 |
1000-4500 |
0.3-3.0 |
When you place an order of the U type Silicon Carbide heating Rod, please give following information:
OD:Outer Diameter;
HZ:Length Of Hot Zone;
CZ:Length Of Cold Zone;
L:Total Length,
A:Shank Spacing
Order Sample of the U type Silicon Carbide heating Rod
U type: OD=20mm, HZ=300mm, CZ=400mm, L=700mm, A=60mm,
Resistance 2.24 Specify As: S-U,20/300/700/60/2.24
Notes for using and installing the heater:
1. Heater should be protected against damp during storing or installing to ensure the performance of the heater.
2. In order to be sure of well-distributed lod of each and groups, heater should be divided before assembling. The tolerance of the resistance of each one cannot exceed by 10% each other.
3. Heater is hard and brittle, please be careful when assem bling and maintaining so as to avoid damage.
4. When operating the electric furnace at the beginning, the voltage should be increased slowly and cannot be fully loaded at once. Otherwise the larger current will be resulted in the damage of heater.
5. When heater is damaged and need to be changed, the resistance of new ne should follow the increasing resistance. If many are damaged or resistance increased too much, heater should be changed.
6. U type Silicon Carbide heating Rod is a non-metal electric heating element made from SiC as its main raw materials. It has some specific properties, such as low expansion coefficient, little deformation, stable chemical property, long service life, easy installation and maintenance, etc.
7. Usage: U type Silicon Carbide heating Rod can usually make use for furnace which temperature from 600-1600. It can be directly used in an air atmosphere, without any protection atmosphere. It is extensively used in the fields of metallurgy, ceramics, glass, machinery, analysis test, semiconductor, science & research and so on.
