STA Ceramic Fiber Blanket(1260 Standard)
1.Product Description:
The ceramic Fiber is made through intensive needle-punching processing . The product does not contain any bond or other compositions,and also no slag inclusion content. The intensive needle-punching technics improved the fiber intertexture and the resistance performance against delamination as well as the tensile strength.It have a good high temperature shrinkage after the heat treatment of 750-950 during the producing. Beside the charicteriatics in common,it have better sound insulation performance and mechanism strength,is easy to machining and install.
2.Product Features:
*Low thermal conductivity ,heat storage and heat capacity
*Excellent heat insulation
*Excellent chemical stability
*Shock and chemical attack resistant
*Low thermal conductivity and shrinkage
*Resilience under working condition, Low shrinkage under high temperature
*Excellent sound insulation and resistance of folding
3.Ceramic fiber blanket application:
*Industrial furnace,Heat treatment,High temperature pipe
*Insulating materials of boiler, turbine and nuclear power
*Insulating material for face and top of industrial furnaces and heating device
*Excellent sound insulation for Construction Fire protection
*High temperature filter material for nonferrous metal.
4.Our advantage:
* We are one of the leading Ceramic fiber manufactures and have the long-term exporting experience.
*15 production lines,high quality equipment and big turnout, which can satisfied your market needs.
* Responsible production lead to high quality
* Fast delivery and favorable price
* The best package
* You can not only get the best products money can buy, but also get our experience and solution. We could to
be the best friend and get the mutual benefits in this field with each other.
4.Technical index:
Type |
Standard |
High Pure |
High Aluminum |
Zir-Alu |
Zirconium |
|
Classification Temp(oC) |
1260 |
1260 |
1360 |
1360 |
1430 |
|
Working Temp (oC) |
1050 |
1100 |
1200 |
1200 |
1350 |
|
Color |
Pure white |
Pure white |
Pure white |
pure white |
Pure white |
|
Density (kg/m3) |
64 |
64 |
96 |
96 |
128 |
|
160 |
160 |
160 |
160 |
160 |
||
Permanent linear shrinkage(%)(after24 hours,128kg/m3) |
-3 |
-3 |
-3 |
-3 |
-3 |
|
(1000oC) |
(1100oC) |
(1250oC) |
(1000oC) |
(1350oC) |
||
Thermal conductivity (w/m.k),128kg/m3) |
0.09(400oC) |
0.09(400oC) |
0.12(600oC) |
0.132(600oC) |
0.16(800oC) |
|
0.16(800oC) |
0.16(800oC) |
0.20(1000oC) |
0.22(1000oC) |
0.20(1000oC) |
||
Tensile strength (Mpa)(128kg/m3) |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
|
Chemical Composition (%) |
Al2O3 |
46 |
47--49 |
52-55 |
45-46 |
39-40 |
Al2O3+SiO2 |
98 |
99 |
99 |
- |
88 |
|
ZrO2 |
- |
- |
- |
5-7 |
15-17 |
|
Fe2O3 |
0.4 |
0.2 |
0.2 |
0.2 |
0.2 |
|
Na2O+K2O |
≤0.3 |
0.2 |
0.2 |
0.2 |
0.2 |
|
CaO+MgO |
0.2 |
0.2 |
0.2 |
- |
0.2 |
|
Size (mm) |
14640x610x13; 14640x1220x13; 7200x610x25; 7320x610x25; 7200x1220x25; 3600x1220x50; 3600x610x50 |
|||||
