Large format digital wood flatbed printer
We are professional manufacturer of UV flatbed printers in China. Established in 2005, now our products have been exported to more than 50 countries such as USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal.Italy.Czech,Turkey,Russia,Poland,Ukraine,Monglia,India,Philippines,Indonesia etc. Welcome your RFQ so that we can give you a specific introduction to help you find your desired modes.
Our machine can print material includes rigid sheets, such as glass, metal, acrylic, pvc board, MDF, and the flexible material, like film, leather, canvas, wall paper, ceiling paper etc.
we can provide the printer with excellent performance & competitive price. You will enjoy our one-stop service.
Ink Type: It's uv curing ink, environment-friendly ink.
Characteristics: water-proof, anti-uv, heat-resistance.
Printing life: 2 years outdoor, and 10 years indoor.
Printing size could be up to 2.5*1.22m
Lead time: It's according to the production amount, usually it will take 15 working days to finish after deposit.
Specification
1) UV Inkjet Flatbed Printer
2) Konica Minolta printhead
3) 360dpi*360dpi-1440dpi*1440dpi
4) C,M,Y,K or C,M,Y,K,LC,LM + White colors
5) CE Certificate
Higher Speed Plus Higher Resolution
Konica print head with JAPAN KM 512MHB-14PL nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi
Ideal Transmission System
USB optical transmission, interference, to avoid printing garbage.
More Application. Application areas includes: decoration industry, glass industry, sign industry, exhibition industry, rigid paperboard packing industry, leather, textile printing industry, artware industry, furniture industry etc.
More Applications
Printed materials could be: glass, ceramic, ceiling, aluminum sheet, wood board, door sheet, metal panel, billboard, acrylic panel, plexiglass, paper board, foam board, PVC expansion board, corrugated cardboard; flexible materials such as PVC, canvas, cloth, carpet, sticky note, reflective film, leather etc.
| General info | Model | Docan UV2512 |
| Print technology | Drop-on-demand Piezo Electric | |
| Working platform | Vacuum or up-down wheels table | |
| Printhead type | KM-512-14PL/KM-512-42PL | |
| Printhead No. | 4/5/6/7/8/10/12/15/16 | |
| Printhead control | Print head temperature & voltage are adjustable by software | |
| Printing size | 2.5*1.22m | |
| Media thickness | 1-100mm | |
| Ink reservoir | Refillable on the fly while printing/1000ml | |
| loating mode | Resto/Servo | |
| Drying system | UV lamp | |
| RIP software | Photoprint/ONYX/Caldera | |
| File format | TIFF, JPEG, Postscript 3, EPS and PDF | |
| Resolution | 360dpi*360dpi 360dpi*720dpi | |
| 720dpi*360dpi 720dpi*720dpi | ||
| 720dpi*1440dpi 1440dpi*1440dpi | ||
| Printing speed | In draft mode up than 45 sq.m ( 8 heads ) | |
| In standard mode up than 36 sq.m ( 8 heads ) | ||
| In high resolution mode up than 22 sq.m ( 8 heads ) | ||
| Ink | Ink type | UV curing ink |
| Printing color | CMYK, LC, LM, W,Varnish(4,5,6,7, double 4 colors) | |
| Printing Asistant System | Printing media | Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board, also flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, etc. |
| Heating system | Standard(Front heater,rear heater,fan) | |
| Color retains | Outdoor:2 years indoor:7 years | |
| Color management | ICC international standard, adjustment curves, density adjustment | |
| Printer info | Power supply | AC220V-240V 50/60HZ (10%) >30A |
| Working conditions | Temperature 20-28°C | |
| Humidity 40% - 60% | ||
| Warranty period | One year | |
| Dimension | 4.52*2.05*1.33m | |
| Weight | 1280kg | |
| Packing details | Outside packing : Packed by solid wooden carton | |
| Inner packing: sealed with anti-rain & rust plastic bubble film | ||
