Docan UV Flatbed Printer UV2512 (2.44m*1.22m Printing Size)

Docan UV Flatbed Printer UV2512 (2.44m*1.22m Printing Size) thumbnail-1
Docan UV Flatbed Printer UV2512 (2.44m*1.22m Printing Size) photo-1
US$ 1 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Docan Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Shanghai, China
Brand Name Docan
Model Number UV2512
Usage Other, glass printer, sign printer, industrial printer
Automatic Grade Automatic
Gross Power 5kw
Dimensions(L*W*H) 4.52*2.05*1.33m

Specifications

UV flatbed printer.
Printing size: 2.44*1.22m . Konica Minolta 512 print heads. Substrate: flatbed materials.



UV flatbed printer



Model: UV2512

Print Technolog: Drop-on-demand piezo electric

Printhead type: KM-512-14PL/KM-512-42PL

Print head control: the temperature and voltage are software adjustable.

Ink characteristic: UV curing ink

Ink reservoir: Riffiable on the fly while printing /1000ml

Drying system: UV lamp

Color management: based on ICC color, curves and density adjustment.

Rip software: Photoprint 10

File format: tiff, jpeg, postcript 3, eps, pdf

Power supply: 50/60Hz ,220v (10%)>20A

Operation environment: temperature 20 to 28 degree

HUmidity: 40% to 60%

printing size: 2.44m*1.22m

Media thickness: 1-80mm

print head number: 4/5/6/7/8/10/15/16/12 pcs

Resolution: 360dpi*360dpi. 360dpi*720dpi.                        720dpi*360dpi.720dpi*720dpi.720dpi*1440dpi.1440dpi*1440dpi

Printing speed: in draft mode up than 52 sq.m/hr. in standard mode up   than 36 sq.m/hr

                         in high resolution mode up than 22sq.m/hr (8 heads)

                         in super resolution mode up than 12 sq.m/hr

Color: 4 colors (CMYK) or 6 colors (CMYK LC LM)   white &varnish can be optional

Outdoor life: 2 years (use DOCAN ink)

Loating mode: resto /servo

Dimensions : 4.52*2.05*1.33m

Packing: Inside: plastic bubble film sealed anti rain and rust. outside: solid wooden carton packing

Weight :1050kgs



We also have other model, eg, UV2518, UV2030, M8.

The printing size of UV2518 is 2.44m*1.8m, The printing size of UV2030 is 2m*3m. The Model M8, the printing size is 2.44m*1.5m.

For detailed information, please send me email.
