16 CH Power, video, data 3 in 1 passive video balun hub mid HY-PVD516J

Specifications

1) 16 CH Power, video, data 3 in 1 passive video balun hub mid
2) CE, FCC, RoHs Compliant
3) Built-in TVS

Features:



        a)      16 CH Power, video, data 3 in 1 passive video balun hub mid

        b)     Use with the power-video-data transceiver at the camera end.

        c)     Built-in passive transceivers with surge protection

        d)     CE, FCC, RoHs compliant, no importing obstruction.



Specification:



Balun Type:	power-video-data
Video transmitting distance	330m
Video Formats:	NTSC, PAL, SECAM
Crosstalk & noise immunity:	60dB
Built-in transient supression protection:	Yes
Frequency Response:	DC to 8MHz
Working temperature:	-10 Celsius to + 70 Celsius
Storage Temperature:	-30 Celsius to + 70 Celsius
Material:	Aluminium-alloy
