Help CenterDocan Large Digital Roll to Roll Printer, Wallpaper Inkjet Printer R3300
Related Products
-
Docan Large Format Roll to Roll UV Printer R5200, Banner Digital Printer 5.2MUS$ 40,000 - 140,000MOQ: 1 Set -
3.2m Ricoh Gen5 Head UV Inkjet Printer/billboard Printing MachineUS$ 70,000 - 100,000MOQ: 1 Set
-
Docan Foam Board MDF Wood Furniture uv Flatbed Printer, Multifunction Digital Printer FR3210US$ 30,000 - 120,000MOQ: 1 Set
-
Docan UV Flatbed Printer FRT3116 With Roll to Roll Function, Hybrid Printer With High ResolutionUS$ 50,000 - 140,000MOQ: 1 Set
-
Docan Large uv Printing Machine, Roll to Roll Vinyl Printer High SpeedUS$ 40,000 - 120,000MOQ: 1 Set
Company Profile
Thanks for your inquiring our UV printers!
Shanghai DOCAN technology is professional UV flatbed printer leaders in China .
Established in 2005, now our products have been exported to more than 30 countries, suchas:USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal,Italy,Czech,Turke,Russia,Poland,Ukraine,Monglia,India,Philippines,Indonesia etc. Welcome your RFQ so that we can give you a specific introduction to help you find your desired modes.
Application material:
Printed materials could be: glass, ceramic, ceiling, aluminum sheet, wood board, door sheet, metal panel, billboard, acrylic panel, plexiglass, paper board, foam board, PVC expansion board, corrugated cardboard; flexible materials such as PVC, canvas, cloth, carpet, sticky note, reflective film, leather etc.
Application Areas:
Decoration industry, glass industry, sign industry, exhibition industry, rigid paperboard packing industry, leather, textile printing industry, artware industry, furniture industry etc.
Our machine can print material includes rigid sheets, such as glass, metal, acrylic, PVC board, MDF, and the flexible material, like film, leather, canvas, wall paper, ceiling paper etc.
We can provide the printer with excellent performance & competitive price. You will enjoy our one-stop service.
UV ink advantage:
Its instant dry feature that leaves the graphic completely cured. It is not easu to clog the print head
UV ink boasts fewer emissions than solvent inks which is more environmental friendly.
UV Ink Features
Ink Type: It's UV curing ink, environment-friendly ink.
Characteristics: water-proof, anti-uv, heat-resistance.
Printing samples life: 3 years outdoor, and 10 years indoor.
Ink Brand: Belgium AGFA
Can print on flexible material and rigid material
Machine Highlights:
Higher Speed Plus Higher Resolution:
Konica print head with 1024-14PL nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi)
Double circulation for white color
One small circulation is the circulation within the ink bottle. when the head cartridge stop, the circulation starts. The pump starts to stir the ink bottle.
One big circulation is the circulation from the ink sub tank to the ink bottle
Beside this , there will be automatic frequency flush on the print head set by the software.
In this way, the white clot on the print head can be get rid of .
Solid Mechanical machine structures
The X axial guide rail is imported from JAPAN THK and taiwan PMI . which is more stable than the belt transmission to prevent of the belt will get loose after half years usage. The Y axial we use double screw pole for transmission.
Material Automatic height testing function
The machine can test the material height automatically.
Print head protection system
Print head anti-crash system can protect the print head by stopping the head cartridge in case of print head crash.
| ||
| ||
| ||
| ||
| ||
| ||
| ||
|
| Model | DOCAN R3300 |
| Print head | KM-1024-14PL |
| Catagory | UV series |
| Print Technology | Drop-on-demand Piezo Electic |
| Nozzle Technology | Piezoelectric Inkjet |
| Print head controls | Print head temperature and voltage are software adjustable |
| Cloth feeding system | Automatic rotary motor can be driven to achieve optimal tension distributing |
| Cloth collecting system | Automatic motor rotatingφ 35cm |
| Material accepted | Roll to roll |
| Ink Characteristics | UV curing ink |
| Ink Reservoir | Refillable on the fly while printing/ 2L |
| Drying system | UV lamp |
| Rip software | Photoprint/ Onyx/ Caldrea |
| Color Management | Icc Based Color, Curves Adjustment, Density Adjustment |
| File Format | Tiff, Jpeg, Postscript 3, Eps and Pdf |
| Power supply | 50/60hz 220v ( 10%) >30A |
| Operation Environment | Temperature 20c to 28c degrees |
| Humidity | 40% to 70% |
| Media width | 3.3m |
| Printing size | 3.2m |
| Media thickness | 2mm |
| Nozzle Number | 4/5/6/7/8/10/12/14/16pcs |
| Resolution | 360dpi*360dpi 360dpi*720dpi |
| 720dpi*360dpi 720dpi*720dpi | |
| 720dpi*1440dpi 1440dpi*1440dpi | |
| Printing speed | In Draft mode up than 65sq.m/h (8 heads) |
| In Standard mode up than 45sq.m/h ( 8 heads) | |
| In High resolution mode up than 36sq.m/h (8 heads) | |
| Colors | 8 colors( double CMYK) to 14 pcs(double CMYK+LC+LM+W) |
| Outdoor life | 3 years(use Docan ink) |
| Dimensions | 5.60*1.50*1.72m |
| Weight | 3630KG |
