Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Docan Foam Board MDF Wood Furniture uv Flatbed Printer, Multifunction Digital Printer FR3210
Docan Foam Board MDF Wood Furniture uv Flatbed Printer, Multifunction Digital Printer FR3210
US$ 30,000 - 120,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Docan UV Flatbed Printer FRT3116 With Roll to Roll Function, Hybrid Printer With High ResolutionUS$ 50,000 - 140,000MOQ: 1 Set -
Docan Large uv Printing Machine, Roll to Roll Vinyl Printer High SpeedUS$ 40,000 - 120,000MOQ: 1 Set
-
Docan Corrugated Cardboard Printer With Automatic Cleaning and Drying System, Hybrid Printer FRT3116US$ 50,000 - 150,000MOQ: 1 Set
-
Docan Flatbed Printer At1440dpi, UV Inkjet Glass PrinterUS$ 40,000 - 100,000MOQ: 1 Set
-
Outdoor UV Printers With Large BedUS$ 40,000 - 100,000MOQ: 1 Set
Condition
New
Plate Type
Flatbed Printer
Place of Origin
Shanghai, China
Brand Name
DOCAN
Model Number
FR3210
Usage
Bill Printer, Label Printer, Paper Printer, Other, Bill Printer, Label Printer, Paper Printer, UV Flatbed Printer
Automatic Grade
Automatic
Voltage
220v
Gross Power
8KW
Dimensions(L*W*H)
5.5*1.6*1.3m
Weight
3125kg
Certification
CE,CCC
After-sales Service Provided
Engineers available to service machinery overseas
Advantages of UV3210 Flatbed and Roll to roll Printer
Our UV roll to roll printer can detect thickness of media automatically and the printer head carriage can go up and down automatically.
It is equipped with automatic cleaning system and print head carriage anti-bumping device.
There are three kinds of printing speeds; draft mode; standard mode and high precision mode
Its tension system can be adjusted continuously.
White print head and innovative structural design.
Optimized ink-jet system and multi-domain vacuum printing platform,
Our UV roll to roll printer adopts Konica Minolta print head.
As a professional UV roll to roll printer manufacturer in China, we strive to provide various high-quality UV printers for our customers, In order to do this, we adopt the newest fiber data transmission mode, which can facilitate the transmission of data and enhance the anti-jamming capability. Furthermore, we develope a specialized control system for UV roll to roll printer on our own.
Technical Parameters of UV Flatbed and Roll to roll Printer UV3210
| Model | DOCAN UV3210 |
| Print head | KM-1024-14PL |
| Catagory | UV series |
| Print Technology | Drop-on-demand Piezo Electic |
| Nozzle Technology | Piezoelectric Inkjet |
| Print head controls | Print head temperature and voltage are software adjustable |
| Cloth feeding system | Automatic rotary motor can be driven to achieve optimal tension distributing |
| Cloth collecting system | Automatic motor rotatingφ 35cm |
| Material accepted | Roll to roll/ Sheet to sheet |
| Ink Characteristics | UV curing ink |
| Ink Reservoir | Refillable on the fly while printing/ 1000ml |
| Drying system | UV lamp |
| Rip software | Photoprint/ Onyx/ Caldrea |
| Color Management | Icc Based Color, Curves Adjustment, Density Adjustment |
| File Format | Tiff, Jpeg, Postscript 3, Eps and Pdf |
| Power supply | 50/60hz 220v ( 10%) >30A |
| Operation Environment | Temperature 20℃ to 28℃ degrees |
| Humidity | 40% to 70% |
| Product Model | Docan UV3210 |
| Media width | 3.3m |
| Printing size | 3.2m |
| Media thickness | 1-60mm |
| Nozzle Number | 4/5/6/7/8/10/12/14/16pcs |
| Resolution | 360dpi*360dpi 360dpi*720dpi |
| 720dpi*360dpi 720dpi*720dpi | |
| 720dpi*1440dpi 1440dpi*1440dpi | |
| Printing speed | In Draft mode up than 60 sq.m/h (8 heads) |
| In Standard mode up than 38sq.m/h ( 8 heads) | |
| In High resolution mode up than 24sq.m/h (8 heads) | |
| Colors | 4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional |
| Outdoor life | 3years(use Docan ink) |
| Dimensions | 5.5*1.6*1.3m |
| Weight | 3125KG |
