uv Flatbed Printing Machine

uv Flatbed Printing Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Flatbed Printer
Place of Origin Shanghai, China
Brand Name DOCAN
Model Number DOCAN M 8
Usage Card Printer
Automatic Grade Automatic
Voltage 220 V
Gross Power 8 kw
Dimensions(L*W*H) 4.63*2.48*1.47m
Weight 1870 KG
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

We are specialized in manufacturing uv printer outdoor uv flatbed printer ,uv printing machine,inkjet printers color printers

We are specialized in manufacturing uv printer  outdoor uv flatbed printer ,uv  printing machine,inkjet printers color printers

The DOCAN UV Flatbed Printer,Outdoor UV Flatbed Printer,Digital UV Flatbed printer  description as follows:



Features of  M8 UV Flatbed Printer
Our M8 UV flatbed printer can print images on all kinds of flatbed materials. Such as glass, acrylic, PVC foam board,  ceramic, aluminum composited panel, corrugated board, aluminum sheet, metal,wave board, wood , MDF,ceiling, wall paper, corrugated paper,timely paste,canvas,leather, etc.
Special treatment to flatbed materials is unnecessary.
The maximum printing material thickness is 80mm.
The printing effect is very good and the images are firmly printed on the panels, This ensures that the printing effect can be well preserved for a long time without fading(indoor for 10 years and outdoor for  3 years.)

Basic Characteristics of  M8 UV Flatbed Printer
Model M8
Catagory  M series
Print Technology Drop-on-demand Piezo Electic
Nozzle Technology Piezoelectric Inkjet
Print head type KM-512-14PL
Print head controls Print head temperature and voltage are software adjustable
Ink Characteristics UV curing ink
Ink Reservoir Refillable on the fly while printing/ 1000ml
Drying system UV lamp
Rip software Photoprint/ Onyx/ Caldrea
Color Management Icc Based Color, Curves Adjustment, Density Adjustment
File Format Tiff, Jpeg, Postscript 3, Eps and Pdf
Power supply 50/60hz 220v ( 10%) >30A
Operation Environment  Temperature 20°C  to 28°C degrees
Humidity 40% to 60%
Product Model Docan M8
Printing Size 2.5*1.8m
Media thickness 1-100mm
Nozzle Number 4/5/6/7/8/10/12/15/16pcs
Resolution 360dpi*360dpi  360dpi*720dpi
720dpi*360dpi  720dpi*720dpi
720dpi*1440dpi 1440dpi*1440dpi
Printing speed In Draft mode up than 58 sq.m/h (8 heads)
In Standard mode up than 42 sq.m/h ( 8 heads)
In High resolution mode up than 34 sq.m/h (8 heads)
In Super resolution mode up than 26 sq.m/h ( 8 heads)
Colors 4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional
Outdoor life 2 years(use Docan ink)
Dimensions  4.63*2.48*1.47m
Weight 1870KG
