Specifications
UV Printer1. Printing size: 2.05m*3.2m.
2. Max. printing thickness: 100mm.
3. Print on glass, acrylic, pvc, etc.
UV Printer
Established in 2005, Shanghai Docan Tech Co.,ltd is a professional UV printer manufacturer. Our machines include UV series and M series. The machines are mainly used in glass industry, craft industry, advertisement industry, leather industry, decoration industry, etc.It can print on glass, acrylic, PVC, aluminum sheet, ACP, wood, ceramic tiles, leather, MDF, corrugated board, waved board, etc.
Equipment model |
M10 |
Print technology |
Drop-on-demand piezo electric |
Print head type |
Konica KM1024-14PL head |
Print head controls |
Print head temperature and voltage are software adjustable |
Ink Characteristics |
UV Curing ink |
Ink Reservoir |
Refillable on the fly while printing/1000ml |
RIP software |
Photoprint 10/Onyx/ Caldera |
Color Management |
ICC based color, adjustment curves, density adjustment |
Drying system |
UV lamp |
File format |
TIFF, JPEG, Postscript3, EPS and PDF |
Power supply |
50/60Hz 220V(20%)>20A |
Operation environment |
Temperature 20°C to 28°C degrees |
Humidity |
40% to 60% |
Product Model |
Docan M10 |
Printing Size |
2.05*3.20m |
Media thickness |
1-100mm |
Numbers of print heads |
4/5/6/7/8/10/12pcs |
|
Resolution |
360dpi*360dpi 360dpi*720dpi |
720dpi*360dpi 720dpi*720dpi | |
720dpi*1440dpi 1440dpi*1440dpi | |
|
Printing speed |
In draft mode up than 60sq.m/h (8 heads) |
In standard mode up than 38 sq.m/h ( 8 heads) | |
In high resolution mode up than 24 sq.m/h (8 heads) | |
Colors |
4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional |
Outdoor life |
2 years(By Docan ink) |
Loating Mode |
Restro/servo |
Dimensions |
4.6*3.93*1.38m |
Packing |
Inner: plastic bubble film sealed anti rain & rust, outside: solid wooden carton packing |
Weight |
2160kg |
