Docan foam board printing machine flatbed uv printer printing machine uv2510

Company Profile
  Thanks for your inquiring our UV printers!
  Shanghai DOCAN technology is a professional UV flatbed printer leader in   China .
  Established in 2005, now our products have been exported to more than 50   countries, suchas:USA,Brazil,Mexico,Chile,UK,Spain,Finland,Portugal,Italy,Czech,Turkey,Russia,Poland,Ukraine,Monglia,India,Philippines,Australia,Malaysia,Indonesia,Africa   etc. Welcome your RFQ so that we can give you a specific introduction to help   you find your desired modeL.

Application material:
  Printed materials could be: glass, ceramic, ceiling, aluminum sheet, wood MDF   board, door sheet, metal panel, billboard, acrylic panel, plexiglass, paper   board, foam board, PVC expansion board, corrugated cardboard; flexible   materials such as PVC, canvas,building mesh, carpet, sticky note, reflective   film, leather,vinyl etc

Application Areas:
  Decoration industry, glass industry, advertising industry, exhibition   industry, packing industry, leather, logo printing industry, artware   industry,home appliance panel(microwave,fridge,heater,etc), furniture   industry,stationery field etc.
  We can provide the printer with excellent performance & competitive   price. You will enjoy our one-stop service.

UV ink advantage:
  1.Its   instant dry feature that makes the graphic completely cured.
  2.It is not easy to clog the print head.
  3.environment-friendly ink.
  Characteristics: water-proof, anti-uv, heat-resistance.

Docan uv flatbed printer

Hybrid uv printer

ROLL2ROLL printer

Application

Almost all the flat   rigid and flex material(thickness≤100mm)

Both flat&roll   material(thickness≤50mm)

roll material       (thickness≤2mm)

Model

M6

M8

M10

UV1212

Hybrid2510

Hybrid3210

R3300

R5200

Printing size(m)

2.5*1.25

2.5*1.80

2.05*3.20

1.20*1.20

2.5*unlimited

3.2*unlimited

3.2m*   unlimited

5.2m*   unlimited

printhead Technology

drop-on demand piezo   electric

printhead control

printhead temperature   and voltage are software adjustable

Printhead type

Japan konica   KM512/konica KM1024/Ricoh GEN5 for option

Printhead   NO.

2/4/5/6/7/8/10/12/15/16   acc to print head type

8/10/12/14/16

8/10/12/14

Ink characteristic

UV curing ink

Ink type

Belgium Agfa

Ink reservior

Reliable on the fly   while printing/1000ml

Color control

ICC based color, curves   and density adjustment

Color option

Cyan,Magenda,Yellow,Black,   Light Cyan, Light Magenda, White,Varnish

Printing resolution

Up to 1440*1440 dpi

Printing speed

Different print head   different speed (pls consult me)

Life of printed

Outdoor more than 5   years; indoor more than10 years

File format

TIFF, JPEG, EPS, PDF,   POSTCRIPT 3

RIP sofware

PhotoPrint/ Onyx /   Caldera

Power supply

220V 50/60HZ (10%)

Power consumption

Less than 8KW

Operation environ

Temperature 20.C to   30.C; Humidity 40% to 60%

Warranty time

One year

Training

free of charge

Installation

We will send technician   to customer workshop for installation and training

Notification

Docan always adopt world first class apare parts   like Japan konica print head, Japan THK guid rail, Italy megadyne   transmission belt, UK primarc uv lamp, Germany JENA grating scale, KNF air   pump, US poll ink filter, Taiwan Delta or Japan Panasonic servo motor, also   the air circulation and electric circuit system main parts are all from Japan   SMC, OMRON, Taiwan TAC, France Schneider and Germany Simens for quality   guarantee. We alomost do uv printer 10 years as Chinese uv printing machine   professionalleader and we only do UV.

Contact

We are looking for   agents in many countries. If interest pls contact me.                                                   Elva lee from Docan                                                                                                                                                                          Cell:18221727181   skype: sld-elva   Email: docan9 at
