Help CenterMini Laser Module Use in Engraving Cutting Machine
Related Products
-
Mini RED Laser Module MarkerUS$ 15 - 45MOQ: 1 Piece -
4mm x 8mm Mini Laser Diode ModuleUS$ 5 - 130MOQ: 100 Pieces
-
4X10mm Mini 1mw 3mw Laser Diode Module for Mini Laser MachineUS$ 5 - 130MOQ: 100 Pieces
-
650nm 1mW Dot Laser Module 4x8mmUS$ 1 - 20MOQ: 10 Pieces
-
5mw Mini Red Laser Diode Module for Barcode Scanner 4x8mmUS$ 1 - 20MOQ: 10 Pieces
Before our Quotation pls confirm the specifications as following,
1 Output power
2 Housing Dimension
3 Working distance
4 Beam size/Line thickness
5 Wavelength
Elite have many types of dot laser diode module for different application. The light spot can e ellipse and round shaped with varied beam size, aperture and divergence. The difference depends on the glass lens or plastic lens. Customers can chose different types according to their specific applications.
-compact size
-FDA ISO2000:2008 IEC
-SGS TUV assessed supplier
-Wide work temperature
-high reliability
Key Features:
• Wide Temp. Operating (-10 to 50°C)
• Low Consumption (< 130mA)
• High Brightness (> 4mW )
• High Stability (>80 %)
• Small Divergence (<0.8 mrad)
Appliction:
• Laser Alignment
• Laser Sight
• Laser Positioning
• Surveying Instrument
• Medical Instrument
• Military Equipment
Note:
1) The Dot laser module has different kinds of lens available for different application. We still have more models like ELxxDxxIG4, ELxxDxxIG5, and ELxxDxxIG10 and so on.
2) Elite Optoelectronics also could offer more kinds of mechanical dimension by customers’ requirements
3) Dot laser module still have more wavelength, such as 405nm 480nm 780nm 808nm 850nm 980nm.
Caution:
1. The laser light is harmful to human body especially to eye no matter what directly or indirectly.
The laser beam shall be observed or adjusted through infrared camera or equivalent.
2. Design your application so that the product is used within the range in the datasheet.
3. The above product specification is subject to change without notice.
