FDA Certify IRS-0200B Infrared Laser Sight with Rail Mount for Rifles
1.Elite IRS-0200B 4mw Non-waterproof Inrared Laser Sight Description:
The IRS-0200B is an infrared laser sight for Rifle and Pistol.
The maximum laser output power is 4mW at 780nm, 830nm, 850nm.
Complete kits include:Laser sight with battery, rail mount, pressure pad switch or ON/OFF slide switch, adjusting screw, wrench.
2.Elite IRS-0200B 4mw Non-waterproof Infrared Laser Sight Applications:
a.Laser alignment
b.Laser sight
c.Laser positioning
d.Surveying instrument
e.Medical instrument
f.Military equipment
3.Elite IRS-0200B 4mw Non-waterproof Infrared Laser Sight Features:
a.Four point alignment system ensure the most accurate
b.Extra lightweight, aircraft aluminum construction
c.Passed vibration and shock test
d.Low consumption:<40mA
e.High brightness
f.High stability
g.Small divergence:<0.2mrad
h.Long life time:>10,000hrs
i.Wide temperature operating: -10-50°C
4.Elite IRS-0200A 4mw Waterproof Infrared Laser Sight Specifications:
Parameter |
Specifications |
Dimension |
Dia.19*72mm |
Housing Material |
Black anodized aluminum |
Wavelength |
635nm or 650nm |
Output Power |
>4mw |
Operating Voltage |
3 VDC (1pc CR123A Battery) |
Divergence |
0.2mrad |
CDRH Class |
Class IIIa |
Switch |
Pressure pad switch or ON/OFF slide switch (optional) |
MTTF |
>5,000hrs |
5.Infrared Laser Sight Series:
| Model | Wavelength | Output Power | Dimension | Dot Size | Battery |
| IRS-0100 | 780nm or 830nm | >4.5mw | Dia.17x76mm | Dia.20mm (at 50m) | CR1/2AA |
| IRS-0200A | 780nm or 830nm | >4.5mw | Dia.19x93mm | Dia.20mm (at 50m) | CR123A |
| IRS-0200B | 780nm or 830nm | >4.5mw | Dia.19x72mm | Dia.20mm (at 50m) | CR123A |
| IRS-0300 | 780nm or 830nm | >4.5mw | Dia.22x123mm | Dia.20mm (at 50m) | CR123A |
| IRS-0400 | 780nm or 830nm | >4.5mw | Dia.15x51mm | Dia.10mm (at 20m) | 3LR44 |
| IRS-0500 | 780nm or 830nm | >4.5mw | Dia.16x48mm | Dia.10mm (at 20m) | 4LR44 |
| IRS-0600A | 780nm or 830nm | >4.5mw | Dia.15x65mm | Dia.10mm (at 20m) | 4LR44 |
| IRS-0600B | 780nm or 830nm | >4.5mw | Dia.15x65mm | Dia.10mm (at 20m) | 4LR44 |
6.CAUTION:
The laser light is harmful to human body especially to eye no matter what directly or indirectly. The laser beam shall be observed or adjusted through infrared camera or equivalent.
7.Elite Laser Sight Complete Kit Package Photo:
8.Elite Laser Sight Mounts Photo:
9.Elite Rail Mount Kits Package Photo:
10.Elite Laser Sight Mounting Assembly Photo:
11. Packaging & Delivery & Payment Information:
MOQ: 100pcs.
Supply Ability: 100,000pcs per month.
Delivery Time: 10-20 days after payment received.
Shipment Term: FOB Xi’an, China.
Payment Terms: T/T, Western Union, Paypal
Shipping Method: DHL/EMS/TNT Air-Express or sea transportation.
12.Warranty:
We offer 12 months limited warranty for our products. Damage due to misuse, Ill treatment and unauthorized modifications and repairs are not covered by our warranty.
13. Elite Factory Photos:
14. Elite Production Process Photos:
15. Meet us on Exhibitions:
a.Shot Show Exhibition held in USA in January.
b.Laser World of PHOTONICS held in Germany in June.
c.Laser World of PHOTONICS held in China in March.
d.Other exhibitions.
