808nm Laser Diode Module Custom Design Industrial Quality
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
ELITE
Model Number:
EL808D05IG1
Payment & Shipping
Payment Methods:
Port of Shipment:
XI AN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
850nm Laser Diode Module Custom Design Industrial QualityUS$ 12.5 - 75MOQ: 100 Pieces -
High Stablity 780nm to 980nm IR Laser Module With TEC Control Powerful LaserUS$ 5 - 130MOQ: 100 Pieces
-
780nm to 980nm IR High Power With TEC Control Laser ModuleUS$ 5 - 130MOQ: 100 Pieces
-
Industrial Infrared Laser PointerUS$ 9 - 99MOQ: 10 Pieces
-
Adjustable Focus Wide Purpose Infrared Diode LaserUS$ 5 - 130MOQ: 100 Pieces
Place of Origin
Shaanxi, China
Brand Name
ELITE
Model Number
EL808D05IG1
Specifications
-custom design-FDA ISO2000:2008
-SGS TUV assessed supplier
-wide work temperature
-high reliability
808nm laser diode module custom design Industrial quality
Features
- Wavelength: 808nm
- High brightness, optical output power: <5.0 mW
- Low operating current: <180mA
- Low operating voltage: 3VDC
- Class IIIa laser, CDRH/ROHS compatible
- Static, Surge, and Reverse Polarity Protected
- Circuit control: Auto power control (APC)
- Operating Temperature: -10 to 50°C
Optical and Electrical Characteristics
Parameter |
Specifications. |
Test Conditions |
Wavelength |
808 nm |
Tc = 25°C |
Output Power |
4 ± 0.8mw |
Tc = 25°C |
Laser Modes |
CW |
|
Transverse mode |
TEM00 |
|
Output Aperture |
< 1.5 mm |
Factory fixed |
Beam Size |
< 8 mm |
Factory fixed @ 10m |
Divergence |
< 0.8 mrad |
Tc = 25 ±3°C |
Stability |
> 80 % |
|
Operating Current |
< 180 mA |
Tc = 25±3°C |
Operating Voltage |
3 VDC |
|
Operating Temp. |
0°C ~ 45°C |
|
Storage Temp. |
-20°C ~ 70°C |
|
Optics |
Glass Lens |
|
CDRH Class |
Class IIIa |
|
MTTF |
8000 Hrs. |
Tc = 25±3°C |
