Specifications
Ten years experience with manufacture and designFDA IEC SGS ISO9001-2008
Low Consumption
High Reliability
Long Life Span
Industrial Laser Module
Key Features
1, High quality industrial laser diode
2, APC driving circuit
3, Low cost
4, High reliability
5, Long Life
Application:
1. Industrial Instruments and Equipments
2. Wild Explore Instruments
3. Military Instruments and Equipments
4. Medical Instruments
Elite could supply industrial infrared laser diode module with wavelengths listed below. It could be customized into different dot, line or cross beams. The main feature is high stability, high reliability and long life span of more than 10,000hrs. It could be applied in infrared lighting, military collimation, infrared surveying, medical usage, etc.
780nm 5mw ~ 3000mw
808nm 5mw ~ 5000mw
830nm 5mw ~ 3000mw
850nm 5mw ~ 3000mw
980nm 5mw ~ 5000mw
Low output power Series (Dot, Line, Cross)
EL780D05IG1,EL780D05IG2,EL780D05IG3,EL780D05IG4,EL780D05IG8,EL780D05IG9…
EL808D05IG1,EL808D05IG2,EL808D05IG3,EL808D05IG4,EL808D05IG8,EL808D05IG9…
EL830D05IG1,EL830D05IG2,EL830D05IG3,EL830D05IG4,EL830D05IG8,EL830D05IG9…
EL850D05IG1,EL850D05IG2,EL850D05IG3,EL850D05IG4,EL850D05IG8,EL850D05IG9…
EL980D05IG1,EL980D05IG2,EL980D05IG3,EL980D05IG4,EL980D05IG8,EL980D05IG9…
| Items | Infared Laser Module | |||
| Wavelength(nm) | 780 | 808 | 850 | 980 |
| Optical Output Power (CW) | 1mW~30000mW | 1mW~5000mW | 1mW~3000mW | 1mW~5000mW |
| Beam Divergence | 0.2~1.0mrad | 0.2~1.0mrad | 0.2~1.0mrad | 0.2~1.0mrad |
| Power Stability | >90% | >90% | >90% | >90% |
| Operating Temperature | -10~45°C | -10~45°C | -10~45°C | -10~45°C |
| Housing Dimension | φ7x25mm, φ10.5x25mm, |
