Laser Module, 445nm Laser Module, 5mW-200mW 445nm Laser Diode Module Dot & Line Beam with Built-in PD
1.Elite 445nm Laser Diode Module Description:
Elite could provide high quality 445nm (Blue) 5mw-200mw Dot & Line laser diode module. Except the models listed below, several more options are available.
Elite could also do customized new Blue Violet & Green Laser Diode Module.
2.Elite 445nm Laser Diode Module Features:
a. High stability and high reliability
b. Compact size
c. Low power consumption
d. Customized solutions for OEM applications
3.Elite 445nm Laser Diode Module (Dot Beam)Specifications:
Model |
Wave Length |
Output Power |
Driver |
Aperture |
Divergence |
Beam Size |
Dimension |
VB445D05VG1 |
445nm |
<3.5mW |
APC |
Dia.4.5mm |
0.2mrad |
Dia.5mm@10m |
Dia.10x35mm |
VB445D05VG2 |
445nm |
<5.0mW |
APC |
Dia.5.0mm |
0.2mrad |
4x8mm@10m |
Dia.12x40mm |
VB445D05VG3 |
445nm |
<3.0mW |
APC |
Dia.6.0mm |
0.1mrad |
Dia.6mm@20m |
Dia.14x50mm |
VB445D10VG1 |
445nm |
<7.0mW |
APC |
Dia.4.5mm |
0.1mrad |
Dia.5mm@10m |
Dia.10x35mm |
VB445D10VG2 |
445nm |
<10.0mW |
APC |
Dia.5.0mm |
0.2mrad |
4x8mm@10m |
Dia.12x40mm |
VB445D10VG3 |
445nm |
<6.0mW |
APC |
Dia.6.0mm |
0.1mrad |
Dia.6mm@20m |
Dia.14x50mm |
VB445D20VG1 |
445nm |
<10.0mW |
APC |
Dia.4.5mm |
0.1mrad |
Dia.8mm@20m |
Dia.12x40mm |
VB445D20VG2 |
445nm |
<14.0mW |
APC |
Dia.5.0mm |
0.2mrad |
6x12mm@20m |
Dia.12x40mm |
VB445D20VG3 |
445nm |
<10.0mW |
APC |
Dia.6.0mm |
0.1mrad |
Dia.6mm@20m |
Dia.14x50mm |
VB445D40VG1 |
445nm |
<20.0mW |
APC |
Dia.4.5mm |
0.1mrad |
Dia.8mm@20m |
Dia.14x50mm |
VB445D40VG2 |
445nm |
<28.0mW |
APC |
Dia.5.0mm |
0.2mrad |
6x12mm@20m |
Dia.14x50mm |
VB445D40VG3 |
445nm |
<20.0mW |
APC |
Dia.6.0mm |
0.1mrad |
Dia.6mm@20m |
Dia.14x50mm |
VB445D60VG1 |
445nm |
<30.0mW |
APC |
Dia.4.5mm |
0.1mrad |
Dia.8mm@20m |
Dia.14x50mm |
VB445D60VG2 |
445nm |
<40.0mW |
APC |
Dia.5.0mm |
0.2mrad |
6x12mm@20m |
Dia.14x50mm |
VB445D60VG3 |
445nm |
<40.0mW |
APC |
Dia.6.0mm |
0.1mrad |
Dia.6mm@20m |
Dia.14x50mm |
VB445D100VG1 |
445nm |
<50.0mW |
APC |
Dia.4.5mm |
0.1mrad |
Dia.8mm@20m |
Dia.16x60mm |
VB445D100VG2 |
445nm |
<70.0mW |
APC |
Dia.5.0mm |
0.2mrad |
6x12mm@20m |
Dia.16x60mm |
VB445D100VG3 |
445nm |
<60.0mW |
APC |
Dia.6.0mm |
0.1mrad |
Dia.6mm@20m |
Dia.14x50mm |
4. Elite 445nm Laser Diode Module Applications:
a. Laser alignment and positioning
b. Industrial instruments and equipments
c. Medical Treatment Instruments
d. Other OEM applications……
5. Why Choose us?
12 years rich industry experience since 2003
SGS TUV assessed supplier
Have FDA, ISO9001:2008, IEC certificates
Cooperation with Top 500 Global Companies like GE, Corning etc.
6. Packaging & Delivery & Payment Information:
MOQ: 10pcs.
Supply Ability: 100,000pcs per month.
Delivery Time: 10-20 days depending on order quantity.
Shipment Term: FOB Xi’an, China.
Payment Terms: T/T, Western Union, Paypal
Shipping Method: DHL/EMS/TNT Air-Express or sea transportation.
7.Warranty:
We offer 12 months limited warranty for our products. Damage due to misuse, ill treatment and unauthorized modifications and repairs are not covered by our warranty.
8.CAUTION:
The laser light is harmful to human body especially to eye no matter what directly or indirectly. The laser beam shall be observed or adjusted through infrared camera or equivalent.
9.Elite QC Flow:
a.Professional Power Meter for double check
b.Qualified professional staff for the beam size/line thickness testing
c.Strictly surface Inspection before load to the warehouse
10.Elite Factory:
11.Elite Production Process:
12.Meet us on Exhibitions:
a.Shot Show Exhibition held in USA in January.
b.Laser World of PHOTONICS held in Germany in June.
c.Laser World of PHOTONICS held in China in March.
