SNK6320D 4 DVB-C/T/T2/S/S2 Tuner and 2 ASI Input To DVB-C/DVB-T Modulator

Add Jacky Skype To Talk Details:Jacky.shineco

Outline

SNK6320D multi-input modulator is SHINECO’s all-in-one device which integrates demodulation, trans-mux and modulation in one case to convert signals into RF output. It is a 1-U case which supports 4 tuner inputs to receive signal from satellite, cable or terrestrial. To meet customers’ various requirements,  SNK6320D is also equipped with 2 ASI input, and output with 2 groups separate ASI ports and 2 MPTS UDP IP port. The output modulated signals are to be received by TVs, STB and etc.

The USB port is designed to record encoded video (TS) and save it in ts files in the USB Keys or Hard Disks, and then the ts files can be playback through the USB port.

The four CAMs/CIs (Optional) accompanied and BISS modules can descramble the programs input from 4 Tuner inputs. Its pluggable structure design greatly facilitates the change of modules (demodulator) as needed.

 SNK6320D 4 DVB-C/T/T2/S/S2 Tuner and 2 ASI Input To DVB-C/DVB-T Modulator

Key Features

* Support 4 DVB-C/T/T2/S/S2 Tuner and 2 ASI input ports

* Support accurate PCR adjusting

* Support PSI/SI editing and inserting

* PID Remapping

* Excellent RF output performance index, MER≥40db

* 2*DVB-T RF out or 4*DVB-C RF out optional;

* 2 separate ASI&IP (2*MPTS over UDP) mirror 2 RF output

* 4 CAM decrypt multiple programs from 4 Tuner input(Optional)

* Support BISS descrambling

* Record encoded TS and playback TS files (*.ts) through USB port

* Support LCD display and keyboard

* Support Web management, Updates via web and USB


Specifications

Input

4 DVB-C/T/T2/S/S2 Tuner (Optional) and 2 ASI input

Tuner Section



DVB-C

Standard

J.83A(DVB-C), J.83B, J.83C

Input Frequency

30MHz-1000Mhz

Constellation

16/32/64/128/256 QAM

DVB-T/T2

Input Frequency

30MHz-999.999Mhz

Bandwidth

6/7/8M bandwidth

DVB-S

Input Frequency

950-2150MHz

Symbol rate

2-45Msps

Signal Strength

-65~-25dBm

FEC Demodulation

1/2, 2/3, 3/4, 5/6, 7/8 QPSK

DVB-S2

Input Frequency

950-2150MHz

Symbol rate

QPSK 1~45Mbauds

8PSK 2~30Mbauds

Code rate

1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

Demodulation Mode

QPSK, 8PSK

Multiplexing

Maximum PID Remapping

128per input channel

Function

PID remapping (automatically or manually)

Accurate PCR adjusting

Generate PSI/SI table automatically

Modulation

DVB-C

Standard

J.83A(DVB-C), J.83B, J.83C

MER

≥40dB

RF frequency

30~999MHz, 1KHz step

RF output level

-20~0dbm(87~107 dbµV),0.1db step

Symbol rate

5.0Msps-9.0Msps, 1ksps stepping

RF Out

4*DVB-C carriers output



J.83A

J.83B

J.83C

Constellation

16/32/64/128/256QAM

64/256 QAM

64/256 QAM

Bandwidth

8M

6M

6M

DVB-T

Bandwidth

6M, 7M, 8M

Constellation

QPSK, 16QAM, 64QAM

Code rate

1/2, 2/3, 3/4, 5/6, 7/8

Guard Interval

1/32, 1/16, 1/8, 1/4

Transmission Mode:

2K, 8K

MER

≥40dB

RF frequency

30~999MHz, 1KHz step

RF Out

2*DVB-T carriers output

RF output level

-20~0dbm(87~107 dbµV),0.1db step

System

Local interface

LCD + control buttons

Remote management

Web NMS

Stream Out

2 ASI out(BNC type)

IP (2*MPTS over UDP) out (RJ45, 1000M)

Language

English and Chinese

Upgrading

Web and USB

General

Dimension

482mm×300mm×44.5mm(W*D*H)

Weight

3.7kg

Temperature

0~45℃(Operation) ; -20~80℃(Storage)

Power

AC 100V±1050/60Hz; AC 220V±10%, 50/60HZ

Consumption




Working Principle
