Shineco SNK636X 4 IN 1 IRD , IRD with Diseqc and Biss Descrambling
Please add Tina skype: shineco.tina for direct discuss and more details
Outline
Shineco SNK636X ird IRD is the new design which integrates demodulation (DVB-C, T/T2, S/S2 optional), de-scrambler and multiplexing in one case to convert RF signals into TS output.
It is a 1-U case which supports 4 tuner inputs, 1 ASI and IP. The 4 CAMs/CIs accompanied can descramble the programs input from encrypted RF, ASI and IP. The CAM requires NO unsightly external power cords, cables, or additional remote control device.
To meet customers’ various requirements, it is also designed to de-mux programs from any input, and output TS over 48 SPTS & 4 MPTS UDP, RTP/RTSP.
Key Features
* 4 Tuner inputs (DVB-C, T/T2, S/S2 Optional)
* 1 ASI & 4 IP (UDP) input
* One CAM can decrypt multiple programs from Tuners/ASI/IP
* IP (48 SPTS, 4 MPTS) over UDP and RTP/RTSP output;
* 4 groups of independent ASI out for tuner/IP passthrough (one-to-one)
* Support maximum 128 PID mapping per input
* LCD display, Remote control and Firmware, web NMS management
* Updates via web
Specification
Input
4x RF (DVB-C, T/T2, S/S2 optional), F type |
1×ASI input for de-mux, BNC interface |
4xIP input for de-mux (UDP) |
|
Tuner Section
DVB-C | |
Standard |
J.83A(DVB-C), J.83B, J.83C |
Input Frequency |
47 MHz~860 MHz |
Constellation |
16/32/64/128/256 QAM |
DVB-T/T2 | |
Input Frequency |
44-1002 MHz |
Bandwidth |
6M, 7M, 8M |
DVB-S
Input Frequency |
950-2150MHz |
|
Symbol rate |
2-45Msps |
|
Signal Strength |
- 65- -25dBm |
|
Constellation |
1/2, 2/3, 3/4, 5/6, 7/8 QPSK |
|
DVB-S2 | ||
Input Frequency |
950-2150MHz |
|
Symbol rate |
QPSK 1~45Mbauds; 8PSK 2~30Mbauds |
|
Code rate |
1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 |
|
Constellation |
QPSK, 8PSK |
|
Output
IP |
48*SPTS over UDP, RTP/RTSP. 1000M Base-T Ethernet interface (unicast/multicast) 4*MPTS over UDP, RTP/RTSP. 1000M Base-T Ethernet interface, for RF in passthrough (one-to-one) |
ASI |
4 groups BNC interface, for RF or IP in passthrough (one-to-one) |
System
Local interface |
LCD + control buttons |
Remote management |
Web NMS Management |
Language |
English |
General
Power supply |
AC 100V~240V |
Dimensions |
482*400*44.5mm |
Weight |
3 kgs |
Operation temperature |
0~45℃ |
Shineco 4 in 1 IRD Principal Chart
How to operate and manageme the equipment by Web?
Connect the PC (Personal Computer) and the device with net cable, and use ping command to confirm they are on the same network segment.
Shineco Company Brief Introduction and Advantage
Chengdu Shineco Technology Company is about 11 years experience in Digital TV headend DVB-C/T/T2/S2/IPTV and DSNG system.
we submitted to support our distributors and clients by means of successful experiences and perfect services. These added values make our products more worthy.
We work from 9:00 am to 24:00 pm to supply timelyservice for clients,if you choose us,we believe that we shall achieve a win-win situation in the future cooperation. All our products enjoy 5 years warantty. Welcome to contact us!
About Packing and Equipment Power Plug
1. For Sample, you can choose DHL, FEDEX,UPS and EMS.
2. For Bulk Order, you can use Air Transport.
