Satellite Receiver(FTA) Tuner Input DVB Over IP Gateway

Name: Satellite Receiver(FTA) Tuner Input DVB Over IP Gateway
Brand: Shineco
SKU: 111242529
Availability: InStock

Satellite Receiver(FTA) Tuner Input DVB Over IP Gateway thumbnail-1

Satellite Receiver(FTA) Tuner Input DVB Over IP Gateway photo-1

US$ 800 - 1,400 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Sichuan, China

Brand Name:

Shineco

Model Number:

SNK6386

Contact Supplier Request Quote Chat Now

Chengdu Shineco Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Main Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Sichuan, China

Brand Name Shineco

Model Number SNK6386

Satellite Receiver(FTA) Tuner input DVB over IP Gateway

Please add Tina skype: shineco.tina for direct discuss and more details

Product Description

Outline

Shineco SNK6386 Tuner (ASI) to IP Gateway is a head-end interface conversion device. It supports SPTSx32 or SPTSx20 (For version with BISS function) output.

It is also integrated with demodulation and gateway function, which can demodulate the signal from 8 tuners (ASI) into TS. After multiplexing the TS, then packet the TS into IP package and output the IP package through different IP address and ports. It supports IP output (UDP, RTP/RTSP protocol).

BISS function is now embedded to descramble your tuner input programs.

Features

* Integrated with demodulation and gateway function

* Support 8 channels tuner (ASI) input

* Support BISS descrambling (Up to 120Mbps)

* 1 GE output, maximum output bit-rate is 800Mbps

* SPTSx32 or SPTSx20 (For version with BISS function) over UDP, RTP/RTSP, unicast and multicast

* Support LCD display and keyboard

* Support SNMP/Web operation

Specifications

Input	8 tuner input(DVB-S/DVB-S2 /DVB-T/DVB-T2/DVB-C/ISDB-T optional) DVB-C: 47 MHz~860 MHz, 16/32/64/128/256 QAM DVB-S: 950 MHz~2150 MHz, symbol rate: 2~45Mbauds DVB-S2: 950 MHz~2150 MHz, symbol rate: QPSK 1~45Mbauds, 8PSK 2~30Mbauds DVB-T: 146MHz ~862 MHz, 6/7/8 M bandwidth DVB-T2: 44MHz ~999 MHz, 6/7/8 M bandwidth ISDB-T: 153 MHz ~862 MHz, 6/7/8M bandwidth
Output	1 GE output, UDP, RTP/RTSP protocol, unicast and Multicast 32 SPTS output — Without BISS function Or 20 SPTS output — With BISS function
BISS descrambling	Mode 1, Mode E
Transmission Bit-rate		Maximum total bit-rate is 800Mbps
General	Dimension(WxLxH)	482mm×410mm×44mm
	Weight	3.6kg
	Temperature	0~45℃(working ),-20~80℃(storage)
	Power supply	100~240VAC,50/60Hz
	consumption	20W
