Directional GSM CDMA Outdoor Yagi Antenna 890-960mhz/633mm length 7 elements 10dbi

SDY890/960

Frequency Range(MHz): 890-960
Gain (dBi) :10
Horizontal/Vertical :3dB Beam Width (°) 60/50
VSWR :≤1.5
Element: 7
Length: 630 mm
Connector: N-Type
Material: Cu Aluminum Alloy

SDY450

Frequency Range(MHz):450-470
Gain (dBi):9
VSWR:≤1.5
Length:860 mm
Connector:SMA Male
Cable Length:According Client
Reflector material:Cu Aluminum Alloy

SDY2400/2500

Frequency Range(MHz):2400-2500MHz
Gain (dBi):12.5
VSWR:≤1.7
Element:12
Length:600mm
Connector:N-Female
Reflector material:Cu Stainless Steel

      SDY145/435

Frequency Range(MHz):

144-146/430-440
Gain (dBi):9.5/11.15
VSWR:≤1.5
Element:3/5
Length:1130 mm
Connector:N female
Material:Stainless Steel，Aluminum Alloy

             SDY66/88

Frequency Range(MHz):66-88
Gain (dBi):7
VSWR:≤1.5
Element:3
Length:1000 mm
Connector:N female or customization
Reflector material:Cu Aluminum Alloy

          SDY220/235

Frequency Range(MHz):220-235
Gain (dBi):12
VSWR:≤1.5
Element:10
Length:1800 mm
Connector:SO239
Reflector material:Cu Aluminum Alloy

SD34   Multi band GSM anetnna

Frequency Range(MHz): 800/900/1800/1900/2100Mhz

VSWR:less than 1.3

                    SD42

Frequency:900/1800MHz
VSWR:less than 1.3
Gain:5.5dBi
Connector:SMA-male
Magnet Base Dia:42mm
Cable: 3m RG174 cable

              SDD5

Frequency：900/1800 MHz
VSWR：Less 1.5
Gain：3.5 dBi
Connector：SMA-male
Color: Black
Hight:55 mm

                  SDT4

Frequency:890-960MHz
VSWR:less than 1.3
Gain:3.5dBi
Max. Power Input:50W
Connector:SMA-male
Cable: 3m RG174 cable

                    SDXQX1

Frequency：890-960 MHz
VSWR：Less 1.5
Gain：3.5 dBi
Connector：N-Female
Color: Gray /White
Hight:185 mm

SDBF0.5F  GSM qual band

Frequency Range: 800/900/1800/1900/2100/2400MHz
VSWR: less than 1.5
Gain: 9.0 dBi
Polarization: Vertical
Maximun Power input: 500W
Connector Type: N-Female
Hight: 500mm
Radome Material: Fiberglass
Color: White

SDD21   Hot style Hot sale

Frequency：900/1800 MHz
Gain：5.5 dBi
Polarization：Vertical
Connector：SMA-male
Color: Black
Hight:210 mm

SDY890/960

Frequency Range: 890-960 MHz
Impedance: 50 ohm
VSWR: 1.5
Gain: 11.0 dBi
Polarization: Vertical
Horizontal 3dB Beam Width: 53°
Vertical 3dB Beam Width: 48°
Front To Back Ratio: >15 dB
Connector: N-Female(or according customer require)
Length: 490 mm
Mounting hardware: Ø40～Ø50 mm

F22 Diamond antenna

Frequency Range: 144MHz
VSWR: less 1.5
Gain: 6.5 dBi
Length: 3200 mm
Radome Material: Fiberglass
Connector: UHF or N-Female

SDBF4.0  Diamond antenna

Frequency Range: 136-174MHz
VSWR: less 1.5
Gain: 8.5 dBi
Dimension: Ø38× 4000 mm
Radome Material: Fiberglass
Connector: UHF or N-Female

  SDBF5.0    CB base atennna

Frequency Range: 26-29MHz or 136-174MHz
VSWR: less than 1.5
Gain: 5.5dBi
Dimensions: Ø36× 3600mm
Radome Material: Aluminum Alloy
Connector: SO239(UHF)

X50 Diamond antenna(hot sale)

Frequency Range: 144/430MHz
VSWR: less 1.5
Gain: 4.5 dBi
Lenght: 1700 mm
Material:  Fiberglass
Connector: MJ/NJ

BC100 Diamond antenna

Frequency Range: 144/430MHz
VSWR: less 1.5
Gain: 5.5 dBi
Dimension: Ø38×1200 mm
Material: Cu and Fiberglass
Connector: UHF

D130 Diamond Discone antenna

Frequency Range: (25 to 1300MHz for receiving) (50/144/430/904/1200MHz for transmitting)
Coaxial cable:RG58A/U
Lenght: 1700 mm
Material: Cu and Fiberglass
Connector: SO239
