100-300m geothermal drilling rigs for sale
- 50 Unit / Units per Month
- Xiamen
- T/T Credit Card
- China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
- 100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
- HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
- 50m Depth Core Drilling Rig Portable Diamond in Mountain
- TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
- 1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
Condition: | New | Type: | Other, water well drilling rigs | Power Type: | Diesel |
Place of Origin: | Fujian, China | Brand Name: | ZHAOXING | Model Number: | KW10 KW20 KW30 |
Usage: | Water Well | Voltage: | 24V | Power(W): | 58KW/80HP |
Dimension(L*W*H): | 5100*2300*2700 | Weight: | 6500kg | Certification: | CE, CE |
Warranty: | 1 Year-2000hours | After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
geothermal drilling rigs for sale1.17 years engineering experience
2.Under ISO9001 quality management system
100-300m geothermal drilling rigs for sale
Features :
Water Well drilling rig characteristics:
1.Safe and stable travelling system
2.Powerful and reliable engine
3.Latest design drilling boom
4.Powerful feeding and rotating system
5.Multi-angle operation
6.Delivery fast (10-14days) Portable Water Well Drilling Rigs
Parameter Technique: | |||
Model | KW10 | KW20 | KW30 |
DIA.hole | Φ115-254 | Φ152-260 | Φ168-300 |
Drilling depth | 120m | 200m | 300m |
Air consumption | 16-30m3/min | 16-30m3/min | 16-40m3/min |
Working pressure | 10.5-24.6bar | 10.5-24.6bar | 1.05-2.46 |
Ground clearance | 245mm | 280mm | 280mm |
Support cylinder stroke | 460mm | 1000mm | 1000mm |
Feed cylinder stroke | 1750mm | 2400mm | |
Feed power | 30000N | 45000N | 50000 |
Lift power | 70000N | 95000N | 150000 |
Speed of rotator | 50-100rpm | 60-105rpm | 43/52/69 |
Rotation torque | 3200N.m | 40000N.m | 40000N.m |
Climb capacity | 15 | 25 | 25 |
Traveling speed | 0-2.5KM/h | 0-2.5KM/h | 0-2.5KM/h |
Recommended compressor | RHP750 | RHP750 | RHP750 |
Engine | |||
Engine model | YC4D80 | YC6B125-K10 | YC6B150Z-T21 |
power | 58KW/80HP | 92KW/122HP | 110Kw |
Rotation speed | 2400rpm | 2200rpm | 2100rpm |
Drilling components | |||
Hammer | DHD360(DTH380) | DHD360(DTH380) | DHD360(DTH380) |
DIA. Of rod | Φ89mm | Φ89mm | Φ89-102mm |
Length of rod | 3m | 3m | 3m |
DIA.hole | Φ115-254 | Φ152-260 | Φ168-300 |
Weight | 6500kg | 8500kg | 9500kg |
Dimension | 5100*2300*2700 | 5100*2300*2850 | 5200*2300*3200 |
The Usage of The Drill Of The Water Well Deep Drilling Product
water well drilling machine is a lightweight, high-efficient, multi purpose hole drilling equipment, the water well drilling is mainly applied in drilling wells, agricultural irrigation wells, geothermal air conditioning hole borehole and other water well drilling, especially for water project in mountains and rock formations. The portable water well drilling is a new hydraulic technology, supporting high torque hydraulic motor rotary propulsion as well as a large bore hydraulic cylinders.
Zhaoxing can help you to improve drilling efficiency and reduce the production cost.
1. Over 17 years practical drilling experience
2.Sold hundreds of drilling rig and air compressor
3. Continue to supply original spare parts and drilling tools
4. Provide professional drilling technical support
NO1.We can supply full range of drilling equipment to satisfy the requirements of the construction engineering and mine production.
Air compressor
Drilling rig
NO.2 We are not only having 17 years rich practical experience, but also have a batch of long-term cooperation top machinery manufactory resource.We provide original spare parts and drilling tools.
NO3.we have wide experience in mining, blast hole, anchor hole, geotherm hole. You can see our project case, and then you will believe our experience can help you.
When you want to purchase equipment, we can supply best configuration according to your project situation.
When you want to improve increase efficiency, we can supply reform project for you.
When you want to decrease drilling tool cost, we can supply good quality and low price product to you.
When your equipment need to repair, we can supply technical service.
In a word, if you cooperation with me, you will get benefit as soon as possible.
Our Certificate
Not only are we one of the premier suppliers of DTH equipment, we have also become specialists in solution based large diameter rock drilling packages, providing not only large diameter hammers and bits, but also shrouded drill pipes, helicoidal pipes and casing advancing systems. Working with you from tender stage to contract completion helps you get your projects completed on time and on budget.
