Help CenterR134A,R404A,R407C,R22 Refrigerant Low Noise FN Series Air Cooled Condenser
Related Products
-
FNV Type Air Cooled Condenser Series For Refrigeration Cold Room, Part of Refrigeration EquipmentUS$ 29 - 999MOQ: 10 Units -
High Quality and Durable FNP Type Air Cooled Condenser Series for Refrigeration Cold RoomUS$ 29 - 999MOQ: 10 Units
-
FN High Efficient Freon Refrigeration Equipment Air Cooled Condenser With Steel Plate and Sprayed Surface R404A,R407C,R134AUS$ 689 - 12,998MOQ: 3 Sets
-
Air Cooled Condenser Series Units With High Performance and QualityUS$ 58 - 10,380MOQ: 1 Set
-
High Quality and High Efficiency Air Cooled Condenser Series for Cold Room Storage, FN Type, CE, CRAANegotiableMOQ: 1 Unit
Specifications
Air Cooled Condenser1.Copper Tube and AL Fin
2.CE Certificate
3.Top Quality
4.High Efficiency
Refrigeration Parts Low Noise Top Quality Air Cooled Condenser
Introduction
Air cooled condenser is a kind of cooling devices by utilizing air which connected with Freon refrigeration equipments. Now we produce FN, FNS type and FNV type air cooled condenser, Air side outlet for FN&FNS type and Air top outlet for FNV type.
Features
1. The outcovering is made of high-quality steel plate with sprayed surface to ensure corrosion resistance, beautiful appearance;
2. Coil adopted staggered permutation,and tighted to fit with Aluminum sheet to ensure high efficiency heat exchange;
3. Units adopted 2.8MPa air tightness test and system sewage discharge treatment;
4. Application for R22,R134a,R404a,R407C etc. refrigerant;
5. FNS condenser utilized large air volume and low speed internal motors with low noise, beautiful appearance; Application for refrigerant equipments which denmand high requirements of noise;
6. FNV condenser have the features of large windward side, high quality heat exchange; external rotor motors used.
Models Specifications
FN S ----- 80 A
FN: Condenser Products Code
S: Type: S(Low Noise Type); V(Air Top Outlet Type); P(Water Spray Type); None(Standard Type)
80:Heat Exchange Area(m2)
A: Model Change Design Code
FN Type Standard Models:FN2 to FN-180
Overall Size
Technical Data:
| Models No. | Heat Exchange Capacity | Area | Fan | Diameter of Interface | ||||
| KW | m2 | Power(W) | Diameter(mm) | Air Flow(m³/h) | Voltage(V) | Inlets | Outlets | |
| FN-2 | 0.6 | 2 | 1×35 | 200 | 410 | 220 | φ10 | φ10 |
| FN-3.4 | 1.0 | 3.4 | 1×35 | 200 | 410 | 220 | φ12 | φ12 |
| FN-4.4 | 1.3 | 4.4 | 1×60 | 250 | 750 | 220 | φ12 | φ12 |
| FN-5.4 | 1.6 | 5.4 | 1×75 | 300 | 1350 | 220 | φ12 | φ12 |
| FN-7.0 | 2.0 | 7 | 1×90 | 300 | 1350 | 220 | φ12 | φ12 |
| FN-8.4 | 2.3 | 8.4 | 1×150 | 350 | 3100 | 380 | φ16 | φ12 |
| FN-11.5 | 3.5 | 11.5 | 1×150 | 350 | 3100 | 380 | φ16 | φ12 |
Overall Size and Installation Size
| Models No. | Overall Size:mm | Installation Size:mm | ||
| A×B×C | D | E | ||
| FN-2 | 320×100×230 | 270 | 65 | |
| FN-3.4 | 320×100×230 | 270 | 65 | |
| FN-4.4 | 370×100×280 | 325 | 65 | |
| FN-5.4 | 440×100×330 | 392 | 65 | |
| FN-7.0 | 440×135×330 | 390 | 90 | |
| FN-8.4 | 500×130×430 | 455 | 95 | |
| FN-11.5 | 480×180×430 | 430 | 145 | |
Products in Factory
