Specifications
rice bran oil expeller2.hot and cold pressing
3.Easy to operate
4.Wide suitability
5.High oil yield
oil press milling and expeller machine ,apply to soybean,sesame,peanut,rapeseeds,walnut,cotton seeds,coconut copra and other vegetable oil seeds.
1.Main technical parameters:
| Model | 6YL-80 | 6YL-100 | 6YL-120 | 6YL-130 | 6YL-160 |
| Screw speed | 30-45r/min | 30-40 r/min | 30-40 r/min | 28-40 r/min | 28-40 r/min |
| gear ratio | 14/42x19/57=1:6.63 | 15/40x15/55=1:9.78 | 15/34x15/55=1:9.59 | 15/38x19/48=1:7.38 | 15/38x15/52=1:8.78 |
| Dimension | 1650x1150x1750 | 1950x1300x1900 | 2050x1350x2000 | 2200x1600x2150 | 2500x1600x2500 |
| Productivity | 80-150kg/h | 150-250kg/h | 200-300kg/h | 250-400kg/h | 450-600kg/h |
| Power | Y160L-6-5.5KW | Y160M-6-7.5KW | Y160L-6-11KW | Y180L-6-15KW | Y200L-6-18.5KW |
| Vacuum pump | Y90S-4-0.55KW | Y90S-4-1.1KW | Y100L1-4-1.5KW | Y100L1-4-2.2KW | Y100L1-4-2.2KW |
| Heater | 2KW | 3KW | 3.3KW | 3.8KW | 4KW |
The above parameters is according to oil material that is refined, separated, flaked, steamed and fired, and the auxiliary equipments are complete with reasonable techniques.
2.Main Characters of our oil press machine:
1.Saving labor: it can save 60% labor for equal output and 40% labor cost per day
for one or two people are able to make production.
2.Widely-used: it can be used to completely press more than 20 kinds of oil crops,
such as peanuts, sesame, vegetable seeds, soybean, oil sunflower and flax
by third levels for one time.
3.Pure oil quality: the vacuum oil filtering is used to remove residue so as to
ensure the pure oil quality and meet the standard of health quarantine.
4.Small land-using: an area of 10-20 m2 workshop can meet the need of production.
3.Main oil seeds:
Raw Material |
Capacity(kg/hr) |
Output Rate(%) |
Cake Residual |
|
Rape seeds |
Hot pressing |
150-170 |
30-38 |
7.5-8 |
Cold pressing |
75-95 |
28-35 |
||
Peanut |
Hot pressing |
150-185 |
35-45 |
7 |
Cold pressing |
65-95 |
32-40 |
||
Soybean |
Hot pressing |
135-160 |
10-16 |
6.5-7 |
Cold pressing |
70-105 |
8-14 |
||
Sesame |
Hot pressing |
150-185 |
44-47 |
6.5-7.5 |
Cotton seeds |
Cold pressing |
95-105 |
10-14 |
5.5-8.5 |
