Specifications
corn germ oil refinery1.good configuration
2.easy to operate
3.field installation
4.best seller crude oil refineries
Continuous corn germ Oil Refinery machine
Process Introduction
Detailed specification of oil refinery
Oil Refinery capacity can be supplied
1T, 2T, 3T, 5T, 10T, 15T, 20T, 30T, 50T, 60T, 80T, 100T, 120T, 150T, 180T, 200T, 250T, 300T/D and 500TPD etc. Our engineer will analyse and design the corresponding equipment list all as per your capacity and request .
Main process of oil refinery
Crude oil→filter→mix→reactor→mix→reactor→centrifugal separation→oil residue
↑ ↓
Phosphoric acid hot water→mix ↓
↓
degumming oil←cooler←dry←centrifuge separation←mix←alkali liquor
↓ ↓
↓ vacuum steam jet pump←steam citric acid
↓ ↓
bleaching earth→mix→decoloring→filter→decoloring oil→mix→heat
↓
refined oil←filter←cool←deodorizing←vacuum
Technical flow chart ,includes ,
1. Neutralizer It’s used for ridding off acid ,degumming .
2. Decolorizer It’s used for ridding off/reducing the color of the oil .
3.Deodorizer It’s used for ridding off odor of the oil .
4. Transfer oil furence It’s used supplying for the heats required to the line ,it could make the
temperature up to 280 degrees.
5. Air pressurer Blow to dry the Clay for decoloring .
6. Oil filter Clear the oil decolorized .
7. Steam producer Producing steams of high temperater for deodorizer .
8. Neutralizing , There is 2 methods according to adding different quantity alikali and different oil temperature .
9. One is weak alkali(10-16 Be) and high oil temperature (75 degrees),who is only used for weak colour and low
acidity; the other is low temperature(20 degrees orso ) and density alkali(20 Be orso),whose is used more .
10. Decolorizer Pump the oil netralized into decolorizer vessel , samely mixing to rise its temperature to
90 degrees, then mixing fr 30 mins,to reduce water to 0.1%
Any other questions,pls contact me without hesitation.
