2014 High Gain Octo Universal Universal Lnb

Name: 2014 High Gain Octo Universal Universal Lnb
Brand: X SQUARE
SKU: 111185287
Availability: InStock

X-Square Technology

US$ 11.8 - 13 MOQ: 500 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

X SQUARE

Model Number:

D28S

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name X SQUARE

Model Number D28S

FTA(Free To Air) Yes

Type Digital

High Definition Yes

Specifications

The best universal ku band lnb
-Low Noise Figure 0.1dB
-HDTV digital ready
-Easy installation
-Waterproof slide-dow

Specifications

The best universal ku band lnb -Low Noise Figure 0.1dB -HDTV digital ready -Easy installation -Waterproof slide-down

Input Frequency Range	LOW Band:10.7~11.7GHz
	High Band:11.7~12.75GHz
Output Frequency Range	Low Band: 950 - 2050MHz
	High Band: 1100 - 2150MHz
Input VSWR	2.5:1
Output VSWR	2.5:1
L.O. Frequency	Low Band 9.75GHz
	High Band 10.6GHz
L.O. Stability	±2MHz @ (-40c~70c)
L.O. Phase Noise	-70dBc/Hz (1KHz Offset)
	-90dBc/Hz (10KHz Offset)
	-110dBc/Hz (100KHz Offset)
Conversion Gain	60dB (TYP)
Gain Flatness	±0.5dB/6MHz; ±2.5dB/IN BAND
Noise Figure	±0.3dB (Typ)
Image Rejection	50dB(Typ)
Output Power	+5dB (Min) (at 1dB gain compression)
Cross Polarization Discrimination	23dB(Min)
DC SUPPLY VOLTAGE	11~14.5V (V),15.5~22V (H)
SUPPLY CURRENT	130mA (MAX)
LOW/HIGH BAND SWITCHING	Low Band: 0Hz HIGH BAND: 22KHz±4KHz
Output Connector	75Ω "F" type female
RELATIVE HUMIDITY	0%~95%
Operating Temperature	-30 °C to +70 °C
