North America Market RG59 CCTV Cable Siamese with UL Listed
RG59 CCTV Cable Siamese
Product Description
(1) RG59 coaxial cable for CCTV camera
Inner conductor: 0.584 /0.81mm Bare Copper
Dielectric: 3.7mm Solid /Faom PE
Shield: Bare Copper or CCA wire braid 85%~95%
Outer jacket: 6.1mm PVC
(2) RG59+2Power combined cable for CCTV camera
RG59 coaxial cable specs:
Inner conductor: 0.584 /0.81mm Bare Copper
Dielectric: 3.7mm Solid /Faom PE
Shield: Bare Copper or CCA wire braid 85%~95%
Outer jacket: 6.1mm PVC
2Power cable secs:
Conductor: Bare Copper 0.5mm2, 0.75mm2, 1.0mm2, 18AWG
(3) Pre-made RG59 with BNC+DC connector cable
Cable: specs are same as above items
Connector:BNC (Male--Male)
DC (Male--Female)
Length: 5m, 10m, 20m, 30m, 40m, 50m, 25FT, 50FT, 75FT, 100FT
rg59 2c coaxial cable electrical properties
| Impedance: | 75+3 Ohm |
| Capacitance: | 50+3pF/km |
| Velocity of Propagation: | 85% |
| Conductor resistance Max: | Inner:16.8 ohms/km Outer:26 ohms/km |
| Return Loss: | 20dB min (5-2150MHz)gbgfbbgfb |
Attenuation |
[@68o F. (20o C.)] | |
| Frequency (MHz) | Maximum (dB/100 ft.) | Maximum (dB/100 m) |
| 5 | 0.46 | 1.5 |
| 50 | 1.31 | 4.3 |
| 100 | 1.80 | 5.9 |
| 200 | 2.56 | 8.4 |
| 400 | 3.66 | 12.0 |
| 800 | 5.34 | 17.5 |
| 862 | 5.58 | 18.3 |
| 950 | 5.86 | 19.2 |
| 1350 | 7.11 | 23.3 |
| 1750 | 8.24 | 27.0 |
| 2150 | 9.33 | 30.6 |
| 3000 | 11.22 | 36.8 |
Application
Used as a distribution cable for indoor CATV,CCTV systems and as a connection cable for satellite systems where lower attenuation required.
Packing 1) Packing Lengths: 100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll Other lengths available according to client's request; 2) Inner packing: Wooden reel, plastic reel, and paper reel available. 3) Outer packing: Carton box, pull out box, pallet available. (Other packing available according to client's request. )
Cable Picture and Package
Factory Show
Certification
Testing Equipment
Exhibition
