Ring die industrial pellet mill
Description of industrial pellet mill
Raw materials of ring die industrial pellet mill are rice husk,peanut shell,corn stalks,corn cob,cotton stalks and other solid scrap material.
After crushing,pressing,densify,molding,the machine makes raw materials small solid pellet virgulate fuel. Biomass wood pellet fuel has a large calorific value, high purity,small volumeand it is renewable energy which is easy to store and transport.
Attractive advantages of industrial pellet mill
1. high output
2. Molding pressing density can be adjusted
3. industrial pellet mill with easy mould replacement,reduce large cost
4. easy operation
5. National standard
6. Reasonable price with CE&ISO approved
7. automatic lubricating device
Technical parameter of industrial pellet mill
| Model | GX-MZLH350 | GX-MZLH400 | GX-MZLH420 | GX-MZLH508 |
| Capacity | 0.4-0.8t/h | 0.8-1.2t/h | 1-1.5t/h | 1.5-2.0t/h |
| Ring die diameter | ø320mm |
ø350mm |
ø420mm |
ø508mm |
| Power | 55kw |
70/90kw | 110kw | 132/160kw |
| Pellet size | ø6mm ø8mm ø10mm ø12mm |
|||
Structure of industrial pellet mill
Industrial pellet mill is mainly composed of Underbed, Gearbox, Spindle Box, Feed Hopper, Granulation chamber, Door Cover, Discharge outlet, Mold, Press Roller, Transmission case, Scraper, Cutter etc.
According to the requirements about industrial pellet mill, our factory also provide supporting equipments of a production line of pelleting process, includes crushing, mixing, drying, pelleting, cooling, packaging.The industrial pellet mill is essential one.
Application of wood pellet made by industrial pellet mill
Wood pellet made by our industrial pellet mill is widely used in heating, life stoves, hot water boilers, industrial boilers, biomass power plants, etc.
Dear customer, when you use industrial pellet mill, please kindly note:
Raw materials moisture content:10-20%
Material length less than 5mm
If you are interested in ring die industrial pellet mill,please feel free to contact me!
Welcome to China.Welcome to visit our factory for industrial pellet mill.
