High quality machine to refine palm oil
The first section :Degumming&Deacidification |
|
1.Flow chart of machine to refine palm oil
Phosphoric acid alkali liquor ↓ ↓ Crude oil→preheating→mix→centrifugal separation→degumming oil ↓ Off-acid oil←cooler←dry ←centrifuge separation←chemical reaction
|
|
2.Main parts of the process of machine to refine palm oil :
|
|
|
3.Introduction of Degumming&Deacidification process of machine to refine palm oil : Degumming: The purpose of degumming is to remove the phospholipid, sugar, protein, trace mental, and some other impurities, which have bad effect on the stability of the oil. Deacidification: Add some certain quantity of alkali to neutralize the free fatty acids. During this process, some soapstock will be produced.The soapstock will be separated from the oil after using the centrifugal machine. |
The second section:Decoloration |
|
1.Flow chart bleaching earth ↓ Degummed oil→mix→decoloring→filter→decolored oil |
2.Main parts of machine to refine palm oil : |
|
|
3.Introduction of Decoloration process of machine to refine palm oil : Mix the oil with activated clay in the oil soil mixing tank, and 1 ton oil needs 5kg clay. Then stir it 10 minutes at 10°C. Next, pump the mixed oil into the decolorization tower. It use steam to heat the mixed oil at 100°C, and the process lasts 30-40 minutes. |
The third section: Deodorization |
|
1.Flow chart Vacuum steam jet pump←steam ↓ Decolored oil→deodorization tower→cool→deodorized oil→filter→refined oil |
2.Main parts of machine to refine palm oil : |
|
3.Introduction of Deodorization process of machine to refine palm oil : |
|
|
|
Customer visit: |
|
Our certificates: |
|
|
