Specifications
1. Crude groundnut oil purification machine2.Low steam consumption
3.Vacuum deodorization
4.PLC control
|
CE&ISO9001 approved crude groundnut oil purification machine
The first section :Degumming&Deacidification | ||||||||||||||||||||||||||||||
|
1.Flow chart Phosphoric acid alkali liquor ↓ ↓ Crude oil→preheating→mix→centrifugal separation→degumming oil ↓ Off-acid oil←cooler←dry ←centrifuge separation←chemical reaction
| ||||||||||||||||||||||||||||||
|
2.Main parts of the process:
| ||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||
|
3.Introduction of Degumming&Deacidification process Degumming: The purpose of degumming is to remove the phospholipid, sugar, protein, trace mental, and some other impurities, which have bad effect on the stability of the oil. Deacidification: Add some certain quantity of alkali to neutralize the free fatty acids. During this process, some soapstock will be produced.The soapstock will be separated from the oil after using the centrifugal machine. | ||||||||||||||||||||||||||||||
The second section:Decoloration | ||||||||||||||||||||||||||||||
|
1.Flow chart bleaching earth ↓ Degummed oil→mix→decoloring→filter→decolored oil | ||||||||||||||||||||||||||||||
2.Main parts of the process: | ||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||
|
3.Introduction of Decoloration process Mix the oil with activated clay in the oil soil mixing tank, and 1 ton oil needs 5kg clay. Then stir it 10 minutes at 10°C. Next, pump the mixed oil into the decolorization tower. It use steam to heat the mixed oil at 100°C, and the process lasts 30-40 minutes. | ||||||||||||||||||||||||||||||
The third section: Deodorization | ||||||||||||||||||||||||||||||
|
1.Flow chart Vacuum steam jet pump←steam ↓ Decolored oil→deodorization tower→cool→deodorized oil→filter→refined oil | ||||||||||||||||||||||||||||||
2.Main parts of the process: | ||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||
|
3.Introduction of Deodorization process The main purpose of deordorization tower is to remove fatty acid and some odor material. The principle of the deordorization is to use the high temperature and vacuum to remove the odor. The fatty acid and odor will be stalled in the storage tank.
Technical parameters of product oil: Crude oil parameter:
Refined oil parameter:
| ||||||||||||||||||||||||||||||
The fourth section: Outside accessories: | ||||||||||||||||||||||||||||||
|
| ||||||||||||||||||||||||||||||
The fifth section:Oil filling line: | ||||||||||||||||||||||||||||||
|
| ||||||||||||||||||||||||||||||
|
The six section:Work shops and installation sites
| ||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||
Customer visit: | ||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||
Our certificates: | ||||||||||||||||||||||||||||||
|
|
