Specifications
Palm fiber dryer:1. Carbon steel material
2.Time delivery in 15 days
3. L/C,or T/T is ok
4.CE and ISO certificate
Hotsale Q345 steel 1.5m*15m CE approved new Guoxin palm fiber rotary dryer with 15-year experience:
1. Brief introduction of the palm fiber rotary dryer:
- It can dry the high moisture content of all kinds of palm fiber under 12%.
- This equipment has national patent technology with the special thermoregulation, material rasing, material guiding, whisking and other devices, which are effectively avoiding to stick to the wall and clog, and more.
- The material has a good color, high quality.
- This device is energy-saving, environment protected.
- New and old customers are well received.
2. Performance of palm fiber rotary dryer:
- The rotary dryer mainly consists of motor, shed plate, transmission device, support device, seal ring, and other spare parts.
- The rotary dryer has the advantages of reasonable structure, excellent manufacture, high output, low energy consumption, convenient operation and so on.
- The rotary dryer is applicable for particle materials, and is also applicable for paste and viscous materials which are mingled with particle materials, or materials whose water content is high.
- It has the advantages of large production volume, wide application range, small flow resistance, large adjustable range, and convenient operation, etc.
3. Working Principle of palm fiber rotary dryer:
- The auto-combustion device provides heat resource for our rotary drier, which adopts down-flow heating method.
- When the mineral materials are fed into the cylinder, it flows down as a result of gravity.
- Meanwhile, they are repetitively scattered in the air so that they are in full contact with the hot air. The material is thus dried gradually.
4. Technical parameter of the palm fiber rotary dryer:
Specific-ations(m) |
Capacity(t/h) |
Main motor |
Main gear box |
Weight(t) |
||
Power(kw) |
Model |
Model |
Speed reduction ratio |
|||
Ø1.2*10 |
2.5 |
7.5 |
Y160M-R3 |
ZL50-16-I |
----- |
13.5 |
Ø1.5*12 |
3.3-4.9 |
10 |
Y160L-6-B3 |
JZQ500-III-2F |
----- |
18.9 |
Ø1.5*15 |
4-6 |
18.5 |
Y200L1-6 |
JZQ500-III-2F |
----- |
21 |
Ø1.8*12 |
4-6 |
18.5 |
Y160L-6 |
ZQ50-16II-2 |
16.46 |
22.83 |
Ø2.2*12 |
7-12 |
18.5 |
Y200L7-6 |
JZQ650-III |
31.5 |
37.6 |
Ø2.2*14 |
7-12 |
22 |
Y200L7-6 |
JZQ650-III |
31.5 |
40 |
Ø2.2*16 |
12 |
30 |
Y225M-6 |
JZQ750-III |
31.5 |
45 |
Ø2.4*14 |
12 |
30 |
Y250M-6 |
JZQ750-III |
31.5 |
51 |
Ø2.4*18 |
10-13 |
37 |
Y250M-6 |
ZL85-13-I |
27.16 |
54 |
Ø2.4*20 |
10-14 |
37 |
Y250N-6 |
ZL85-13-I |
27.16 |
54.14 |
Ø3*20 |
25 |
55 |
Y250M-4 |
ZL100-16-I |
41.52 |
78 |
Ø3*25 |
32-36 |
75 |
YR280M-4 |
ZL100-16-I |
41.52 |
104.9 |
5. Our rotary dryers have passed the CE certificate:
6. The clients in the workshop:
We can also design it according to your drawings and specifications, welcome to contact us!!!
