Specifications
self loading concrete mixerCan work independently, and with the corresponding batching unit synthetic simple mixing station.
WJ-JS500 Hot Sales Self Loading Concrete Mixer(CE)
Introduction:
The machine is suitable for various types of precast plant and water, roads, bridges, industrial and civil engineering construction department mixing dry concrete, flowing concrete, lightweight aggregate concrete and mortar. Can work independently, and with the corresponding batching unit synthetic simple mixing station. Because the discharging in different ways are: Manual ( JS500 ), power ( JS500D ) and dynamic ( JS500Q ). The product has the advantages of reasonable structure, mixing quality, short time, low energy consumption, low noise characteristics. Electrical control system of main parts are imported components, excellent performance, high reliability.
This machine discharge height are 1.5m, 2.7m, 3.8m three ( or users ), the user can be dispensed from a dump truck or a concrete mixing truck supporting the use of.
Technical parameters:
Feeding Capacity: 800L
Discharging Capacity: 500L
Rotating Speed of Stirring Shaft: 23r/min
Motor Power: 18.5kw
Lifting Speed of Hopper: 25m/min
Pump Motor: 0.55kw
Max. Diameter of Aggregates: 60/80
Stirring Time: 30-35s
Standard Height of Discharge: 2200mm
Dimensions in Transporting State: 3400/2300/2700
Mass: 4000kg
