TOBEMAC ATCM 550 Self-loading Concrete Mixer with hydraulic Diesel engine
TOBEMAC Tilting drum concrete mixer are very popular all over the world, both for industry purpose and DIY jobs, According to the requirements of different customers, we have developed several kinds of concrete mixers for you as reference.TOBMAC provides two flexible packages on either production or trading, which enables the clients to get the best machines on the lowest price.
Otherwise, the power units is optional, which would be euqipped with diesel engine, petrol engine or electric motor.
Model |
ATCM-500 |
Hopper Tipping |
By Hydraulic |
Drum Tilting |
By Hydraulic |
Charging Capacity |
500 Litre |
Reclaiming Capacity |
470 Litre |
Bucket loading time |
8s |
Drum discharging time |
4.5s |
Productivity |
12-16 m³/h |
Speed of Mixing Drum |
30 r/min |
Max.aggregate size |
60 mm |
Power Type |
Air-cooled Diesel Engine 10 HP |
Water tank capacity |
60 Litre |
Outside dimensions (LxWxH) |
2,000 X 2,000 X 2,700 mm |
Weight |
1000 kgs |
1.Outside package: Standard Iron Cases
2.Inner package: Stretch film
3.Container Loading Plan: 5 Units/20GP, 10 Units/40HC
Our Services
As a professional exporter,our target is to serve worldwide clients with high-quality products, great, reliability,devoted responsibility,professional services and honorable credibility to meet customers' requirements in all aspects.
Application
Diesel concrete mixer is usually used on ordinary construction sites,roads,bridges projects and concrete prefabricated parts factories.
Successful cases
Diesel concrete mixer has been successfully sold to Mongolia, Uzbekistan, Kazakhstan, Congo, Nigeria, Singapore, Ghana, Libya, Chile, Philippines, Kenya,etc. What's more, they have received praise with good quality and excellent after-sale service.
Q:Can i buy 1 sets as sample to test the quality?
A:Of course you can.As a professional manufacture of concrete mixer, we have no limit for the quantity.
Q:How can i get the promise of the delivery and quality?
A:You can place the order through Alibaba Trade assurance system. We have $21000 guarantee for you!
