2015 TOBEMAC JZG 350 Self-Loading Concrete Mixer
1. It is a middle capacity self-dumping mixer;
2. Heavy duty channel chassis provides durability and stronger support in the areas where you need it
3. Jack legs give maximum stability throughout the mixing cycle;
4. Towable chassis with pneumatic tyred wheels;
5. Hopper lifting model: Hydraulic tipping hopper. Steel wire rope hoisting tipping hopper is available.
6. Power source: diesel engine. So it can also be used in areas without electricity supply.
Model |
JZG 350 |
|
Loading Capacity |
560 L |
|
Discharging Capacity |
350 L |
|
Productivity |
10-14 m³/h |
|
Maximum Size of Aggregate |
60 mm |
|
Hopper Lifting |
Steel wire rope |
|
Diesel Engine |
SIFANG |
YANMAR |
Diesel Engine Power |
15HP |
18HP |
Power of Water Pump |
0.75 KW |
|
Displacement of Gear Pump |
20 ml/r |
|
Pressure of Reversing Value |
16 Mpa |
|
Accuracy of Water Supply |
Error≤2 % |
|
Tyre Size |
6.50-16 |
|
Speed of Mixing Drum |
14 RPM |
|
Overall Size(L×W×H) |
2750*2150*3170 mm |
|
Overall Weight |
2100 KG |
|
JZG350 CONCRETE MIXER WITH WIRE-ROPE HOPPER
JZF350 CONCRETE MIXER WITH HYDRAULIC HOPPER
Our Services
As a professional exporter,our target is to serve worldwide clients with high-quality products, great, reliability,devoted responsibility,professional services and honorable credibility to meet customers' requirements in all aspects.
Application
Diesel concrete mixer is usually used on ordinary construction sites,roads,bridges projects and concrete prefabricated parts factories.
Successful cases
Diesel concrete mixer has been successfully sold to Mongolia, Uzbekistan, Kazakhstan, Congo, Nigeria, Singapore, Ghana, Libya, Chile, Philippines, Kenya,etc. What's more, they have received praise with good quality and excellent after-sale service.
Q:Can i buy 1 sets as sample to test the quality?
A:Of course you can.As a professional manufacture of concrete mixer, we have no limit for the quantity.
Q:How can i get the promise of the delivery and quality?
A:You can place the order through Alibaba Trade assurance system. We have $21000 guarantee for you!
