10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft

10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft thumbnail-1
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft thumbnail-2
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft thumbnail-3
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft thumbnail-4
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft thumbnail-5
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft thumbnail-6
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft photo-1
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft photo-2
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft photo-3
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft photo-4
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft photo-5
10mm 3.7V Coreless Motor CL-1020D With High Torque and Speed for 4 and 6 Axis Aircraft photo-6
US$ 2.5 - 3.5 MOQ: 1000 Units
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
chaoli
Model Number:
CL-1020D
Contact Supplier Request Quote Chat Now
Guangdong Chaoli Motor Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shantou guangdong china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name chaoli
Model Number CL-1020D
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance, Other, Boat, Car, Electric Bicycle, Fan, Home Appliance, airplanes, robots and six-axis aircrafts
Certification CE, ROHS
Type Micro Motor
Torque 88gf.cm
Construction Permanent Magnet
Commutation Brush
Protect Feature Totally Enclosed
Speed(RPM) 46000r/min
Continuous Current(A) 180mA
Output Power 1~8W
Voltage(V) 3.7
Efficiency IE 3



Product Description

 1.This product

  • Below are the specifications and structures of the product, for more information, please feel free to contact us.
  • Furthermore, we provide customizable service of micro dc motor/generator, including consulting, design and manufacture services, all the products are made to your order.

 10mm 3.7V coreless motor CL-1020D with high torque and speed for 4 and 6 axis aircraft
 10mm 3.7V coreless motor CL-1020D with high torque and speed for 4 and 6 axis aircraft



Special features/structure:
Motor type: PMDC coreless motor
Motor housing (D*F* L): Φ10*20.8mm
Housing material: SECD-O
Shaft (diameter): 1.0mm SUS304 steel (nickel coating)
Way of commutation: precious metal-brush
Structure: 2-pole stator and hollow cup type
Magnet type: Nd-Fe-B
Rotation: CW/CCW and reversible
Weight: 7.5g (approximate)
Options:
Length and shape for the extended shaft
EMI/EMC suppression
Gear, eccentric wheel or reducer increased
Magnet type
Wire diameter and turn number

Key parameters/performance
Rated voltage: 3.7V DC
At no load:
Speed: 46000rpm
Current: 180mA
At stall:
Current:11.563A (maximum)
Torque: 87.8gf.cm


This product is widely used in: medical equipment, industrial equipment, navigation models, electrical tool and household appliances.

Provide high quality, Bring honorable value.





2.Our products



Following are the main products of our company, including coreless dc motors, brush dc motors, brushless dc motors, flat vibration motors and micro generators, etc., covering a wide range of around 1,000 products.



10mm 3.7V coreless motor CL-1020D with high torque and speed for 4 and 6 axis aircraft

10mm 3.7V coreless motor CL-1020D with high torque and speed for 4 and 6 axis aircraft







Our advantages:

.Specialized manufacture

. Complete variety of product

.Volume production ability

.Reasonable pricing with high quality

.Short leading time, customized service





Please send us inquiries table including specifications



for the performance and structure requirements .
