Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > Baby Feeding Nipple Making Machine
US$ 1 - 46,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Vertical Injection Molding MachineUS$ 1 - 8,000MOQ: 1 Set -
Machine for Making Electric PlugUS$ 1 - 8,000MOQ: 1 Set
-
Plastic Injection Machine 35tonUS$ 1 - 8,000MOQ: 1 Set
-
55ton Injection Molding Machine- Power Plug -insert or FinishedUS$ 1 - 11,000MOQ: 1 Set
-
Plastic Injection Molding Machine Vertical TypeUS$ 1 - 8,000MOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Vertical
Brand Name
Yatai
Model Number
V85SD-LSR
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
176-223cm³
Injection Rate
107mm/s
Clamping Force
85ton, 85ton
Opening Stroke
420-520mm
Power(W)
15kw
Certification
ISO9001,CE
After-sales Service Provided
Overseas service center available
Product Description
| Model No. | V85SD-LSR(Double Slides) | |||||
Injection Unit | Screw Diameter | mm | 40 | 45 | ||
| Theoretical Injection Volume | cm3 | 176 | 223 | |||
| Max.Injection Pressure | Mpa(kgf/cm2) | 146(1492) | 115(1176) | |||
| Injection Rate | cm3/s | 134 | 170 | |||
| Injection Speed | mm/s | 107 | ||||
| Screw Speed Rotation | r.p.m | 0-300 | ||||
| Nozzle Out From Platens | mm | ≥45 | ||||
Clamping Unit | Clamping Force | KN(tf) | 833(85) | |||
| Clamping Stroke | mm | 250 | ||||
| Min.Mold Thickness | mm | 170(270) | ||||
| Max.Opening | mm | 420(520) | ||||
| Distance Between Tie Bars | mm | 500*385 | 658*335 | --- | ||
| Max.Mould Size | mm | 550*470 | 500*475 | 340*340 | ||
| Platen/Slide Size | mm | 620*490 | 1135*495 | 980 | ||
| Ejector Distance | mm | 75 | 75 | 75 | ||
| Ejector Force | KN(tf) | 26.5(2.7 | 26.5(2.7) | 45(4.6) | ||
| Others | System Pressure | Mpa(kgf/cm2) | 13.7(140) | 13.7(140) | 13.7(140) | |
| Oil Tank Capacity | L | 280 | 280 | 310 | ||
| Electric Power | KW(HP) | 15(20) | 15(20) | 15(20) | ||
| Machine Dimensions | L*W | mm | 2140*1410 | 2090*1700 | 2145*1772 | |
| H | mm | 2736(3456) | 2730(3470) | 2760(3500) | ||
| Machine Weight | tf | 3.35 | 3.7 | 4.3 | ||
Packaging & Shipping
1. Before shipping,we will check and test plastic injection molding machine carfully
2. We will arrange to manufacture the second day after confirmation,we can delivery it usually after 30 days
3. According to the destination,we will compare several transportation companies and select the most suitable and economic one to provide service for us
Our Services
1. Provide free guidance of before you start use our plastic injection molding machine
2. 1 year warranty
3. Free remote guidance by video chat when you have problem during use the injection molding machine
