Product: Power Capacitor,film capacitors,shunt capacitor
Application: High-voltage Shunt Capacitor (BFM) is used for AC power system of power frequency at 50 or 60Hz to increase the power factor of system, improve the quality of voltage, reduce the loss of line.
Technical performance
1. Comply with Standards: The High-voltage shunt capacitor is accordance with GB/T11024.1<Shunt capacitors for a.c. power systems having a rated voltage above 1kV> (equivalent to IEC60871.1) and Ministry of Electric Power standard DL/T840-2003 < Specification of High-voltage shunt capacitor for order>
2. Capacitor terminal support frequency at 2.15Un ac voltage last 10s.
3. Capacitance allowance: -0.5%~+10%.
4. Dielectric loss Angle tangent tgδ≤0.00005.
5. Steady-state Over current not exceeds 1.43In.
6. Continuous operating voltage is 1.05 UN, and can operation max 8 hours under 1.1Un every 24 hours
Service condition
1. Altitude less than 1000m;
2. Ambient temperature: -40°C~+45°C;
3. No strong mechanical vibration at installing. No corrosive gas, inductive dust, and in flammable and explosive media in the ambient environment.
*We can also request customized according to your parameters.
