Chocolate refiner and conche
The tank of chocolate conche is jacket, it is heated by electric heating tubes. The behind cover is installed with the ventilating fan, surface cover (shell) is SUS304, others are made by carbon steel with paint.
The material of the lining bars and scrapers(blades) are 65Mn after heating treatment, it can prelong their life. The base and gear box are cast iron, so it will be more stable and can make sure the fineness degree.
Technical data
Model |
Max . capacity(L) |
Finesse degree (μm) |
WorkingTime(h) |
power(kw) |
Weight (kg) |
Dimension (mm) |
JMJ40 |
40 |
25-20 |
7-9 |
2.2+2 |
360 |
1100*800*1100 |
JMJ500A |
500 |
25-20 |
12-16 |
15+6 |
2800 |
2500*1080*1370 |
JMJ1000A |
1000 |
25-20 |
14-18 |
22+6 |
3500 |
2780*1330*1800 |
JMJ2000 |
2000 |
25-20 |
16-20 |
37+9 |
5300 |
3320*2000*1950 |
JMJ3000 |
3000 |
25-20 |
18-22 |
55+9 |
8500 |
4200*2000*1950 |
