Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > New Arrival Economical 16channel Cctv DVR,2 Channel Mini Dvr

New Arrival Economical 16channel Cctv DVR,2 Channel Mini Dvr

Name: New Arrival Economical 16channel Cctv DVR,2 Channel Mini Dvr
Brand: Aliviz
SKU: 111063333

New Arrival Economical 16channel Cctv DVR,2 Channel Mini Dvr thumbnail-1

New Arrival Economical 16channel Cctv DVR,2 Channel Mini Dvr photo-1

US$ 62 - 65 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Aliviz

Model Number:

AS-9616

Contact Supplier Request Quote Chat Now

Aliviz Security (Shenzhen) Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Aliviz

Model Number AS-9616

16CH D1 DVR with different case optional.

FEATURES

1.Support 16ch Full D1 real time recording resolution, ahead to D1 High-Definition period.
2.Dual-stream design, network remote view effects and local recording effects
   parameters can be set separately, independently of each other.
3. Hexaplex operation simultaneously: Preview, recording, playback, backup, network
   live, mobile phone view
4. Support Multiple channel playback (Support 16CH playback simultaneously, each
   channel can be enlarge to full screen)
5. Support Network function: one IE browser centralized monitoring and CMS Software
for multiple DVR (up to 255 DVR simultaneously)
6. Supports Built-in free DDNS domain name, with Server address:
7.Support Mobile phone remote view by Symbian S60V3/V5; Windows Mobile;
Android system; Ip hone; Blackberry
8.Support alarm triggered recording will send alerts matter to the designated email.
9. System auto recovery to power after power reconnected, and return to the pre-power-down state

SPECIFICATION

16CH H.264 DVR(AS-9616F)
Video/Audio Input &Output	Video Compression	H.264
	Audio Compression	8kHz*16 bit ADPCM
	Operation System	Linux
	Video System	NTSC / PAL
	Video	BNC: 16-ch inputs / BNC: 2-ch outputs
	Audio	RCA :16-ch inputs / RCA2-ch outputs
	Preview Resolution	PAL: 704x576; NTSC: 704x480
	Display Frame Rate	NTSC: 240fps / PAL:200fps (shared by 4 cameras)
	Recording Frame Rate	NTSC: 480fps@ CIF /240fps@ HD1/ 120fps@D1
	Recording Frame Rate	PAL:400fps@ CIF /200fps@ HD1/ 100fps@D1
	Record Mode	Schedule / Motion Detection / Sensor Triggered / Remote Recording
	Display	Single / Quad / S.E.Q.
Hard Disk Driver	Interface Type	4 SATA Fixed HDD
Hard Disk Driver	Capacity	Each supports more than 2000GB capacity
General	Network Interface	RJ45 10M/100M /1000M Ethernet Interface
	Network Protocol	Support TCP/IP, UDP, DHCP, DNNS, PP POE
	Network Function	Support to live view with IE (Internet Explorer) & with Mobile Phone
	USB Interface	USB 2.0 for Mouse and File Backup / Upgrade
	Serial Interface	1 RJ45 RS-232 interface; 1 RS-485 interface (for PTZ control); 1 RS-485 keyboard interface (for keyboard control)
	Mobile Surveillance	Support Mobile Phone based on Windows Mobile, Symbian, IPHONE, Blackberry and Android operation system
	Back Up	AVI file via USB flash / USB disk / USB CD/DVD-RW & Network
	Playback Mode	Normal Play / Fast Forward / Fast Rewind / Frame by Frame
	Recording Pack Time	15/30/45/60mins Selectable
	Sensor & Alarm I/O	8-ch sensor input / 1-ch alarm output
	Power Supply	DC12V / 5A
	Consumption	≤30W (without hard disk or DVD-R/W)
	Working Temperature	-10°C~+55°C(14°F~131°F)
