API 9A 1/2~2 In Steel Wire Rope
US$ 300 - 5,000
MOQ: 3 Tons
Key Specifications
Get Latest Price
Steel Grade:
carbon steel
Standard:
BS, DIN, GB, JIS
Wire Gauge:
1/2~2 In
Payment & Shipping
Payment Methods:
Port of Shipment:
China Main Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Steel Grade
carbon steel
Standard
BS, DIN, GB, JIS
Wire Gauge
1/2~2 In
Place of Origin
China
Type
Drawn Wire
Application
Other, Drilling Component wire
Alloy Or Not
Is Alloy
Special Use
Free Cutting Steel
Brand Name
GM
Specifications
API 9A Wire Rope1. High strength
2. Good toughness
3. Large breaking force
4. Non-looseness and long service life.
API 9A Wire Rope
Description
The wire rope features high strength, good toughness, large breaking force, non-looseness and long service life. The diameter ranges from 13 mm to 51mm (0.5-2 in). Our wire ropes according to the standards of API, ISO, BS, DIN, and JIS.
| Service and Well depth | Wire rope diameter | Wire rope description(Regular lay) | ||
| in | mm | |||
| Rod and Tubing pull lines | Shallow | 1/2~3/4 | 13~19 | 6*25FI+IWRC 6*26SW+IWRC 6*31SW+IWRC 18*7; 19*7 PF,LL,IPS or FIPS |
| Intermediate | 3/4, 7/8 | 19,22 | ||
| Deep | 7/8-1 1/8 | 22-29 | ||
| sand lines | Shallow | 1/4-5/8 | 6.5,16 | 6*7+FC PF,RL,PS or IPS Bright or GALV. |
| Intermediate | 1/2, 9/16 | 13,14.5 | ||
| Deep | 6/16, 5/8 | 14.5,16 | ||
| Drilling lines-cable tool (Drilling and cleanout) | Drilling Lines-cable Tool | 5/8, 3/4 | 16,19 | 6*21 FI+FC PF or NPF RL or LL; PS or IPS |
| Shallow | 3/4, 7/8 | 19,22 | ||
| Intermediate | 7/8, 1 | 22,26 | ||
| Casing lines-cable Tool | Shallow | 3/4-1 1/8 | 19,22 | 6*25FI+FC or LWRC, 6*265W+FC(or)IWRC PF,RL,IPS.PS or EIPS |
| Intermediate | 7/8, 1 | 22,29 | ||
| Deep | 1, 1 1/8 | 22,29 | ||
| Drilling lines-coring and slim-hole rotary rigs | Shallow | 7/8, 1 | 22,26 | 6*26SW+LWRC 6*19S+LWRC 6*26SW+LWRC PF,RL IPS; PS or EIPS |
| Intermediate | 7/8, 1 | 26,29 | ||
| Horse-head pumping-unit lines | Shallow | 1/2-1 1/8 | 13-29 | 6*19+FC or IWRC 6*37+FC or IWRC 19*17FC or IWRC,PF,RL,IPS |
| Intermdiate | 5/8-1 1/8 | 16-29 | ||
| Rod janger lines | 1/4 | 6.5 | 6*19+FC; PF, RL | |
| Offshore anchorage lines | 7/8-2 1/4 | 22-70 | 6*19class+IWRC 6*37 class+IWRC 6*61 class+IWRC PF.RL, IPS or EIPS Bright or Galvaniced | |
| 1 3/8-4 1/4 | 35-122 | |||
| 3 3/4-4 1/4 | 96-122 | |||
| Guideline, Tensioner lines | 3/4 | 19 | 6*25 class+IWRC PF, RL, IPS or EIPS | |
| Mast Raising lines | <<1 3/8 | 35 | 6*19 class+IWRC 6*37 class+IWRC PF.RL, IPS or EIPS | |
| >>1 1/2 | 38 | |||
| Raiser Tensioner lines | 1 1/2-2 | 38-51 | 6*37 class+IWRC PF.RL or EIPS | |
