high pressure water pumps high pressure pump
Specifications:
Max pressure: 500bar
Water flow: 40 lpm ~ 170 lpm
Engine: electric motor drive or diesel engine. Power: 30 kw~ 90 kw
Electric-powered: Typically used indoors because there are no fumes and they are quieter.
Diesel-powered: Self-contained and portable so they can be used in the field (no electric cords); all you need is water.
Main Features:
1.For the machine, pump is making with the tech. of Germany WOMA.
2.Small volume, bigger power, compact structure
3.Operates smoothly and suitable for long time continuous working.
Applications:
1.Pipe pressure test, hose pressure test, hydro pressure test, etc.
2.Shipyard rust removal, paint removal
3.Breweries yeast, sediments and fermentation residues on vats, pipe and facilities cleaning.
4.Aviation: expansion joints, grease, rubber and hydraulic fluid on runways cleaning.
5.hydropower station/ dam/dike concrete work treating.
6.Casting clean scale removal rust removal paint, removal sand.
7.Industrial pipe cleaning, such as starch factory, cement plant, etc…
Technical parameters:
speed of motor(r/min) |
1480 |
Stroke(mm) |
95 |
|||||||
Reduction ratio (i) |
3.65 |
speed of pump (r/min) |
405 |
|||||||
Power (KW) |
30 |
37 |
45 |
55 |
75 |
90 |
Plunger diameter (mm) |
|||
Rate Flow |
Rate Pressure (Bar) |
|||||||||
m3/h |
L/min |
|||||||||
2.4 |
40 |
370 |
460 |
|
|
|
|
22 |
||
3 |
50 |
300 |
360 |
450 |
|
|
|
25 |
||
3.42 |
57 |
260 |
320 |
400 |
500 |
|
|
26 |
||
3.9 |
65 |
230 |
280 |
350 |
450 |
|
|
28 |
||
4.5 |
75 |
200 |
250 |
300 |
380 |
500 |
|
30 |
||
5.1 |
85 |
170 |
220 |
260 |
340 |
450 |
500 |
32 |
||
6.12 |
102 |
150 |
180 |
220 |
280 |
360 |
430 |
35 |
||
8.1 |
135 |
110 |
140 |
170 |
210 |
280 |
330 |
40 |
||
10.2 |
170 |
90 |
110 |
140 |
170 |
240 |
280 |
45 |
||
This products could be made according to customer’s request.
If you would like more information, please do not hesitate to contact us . We will reply to you as soon as possible.
Contact information:
Name: Sarah
Skype: jycleaner1
Mobile: +86 15638115232
