Large tunnel x ray baggage scanner for europe market.x-ray baggage scanner europe
Model: XJ5335
General Specifications
Tunnel Size : 530(W)×350(H)mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 150 kg
Single inspection dosage: <1.01μGy
Leakage radiation: <0.06µGy/h
Wire Resolution: 34AWG
Steel Penetration: 12mm
Film Safety: For ISO 1600
X-RAY GENERATOR
Orientation: Upward
Tube Current: 0.2-1.25mA(adjustable)
Anode Voltage: 80-160KV(adjustable)
Angle: 80°
Generator cooling/working periods:
Sealed oil bath with forced air/100%
OPERATING ENVIRONMENT
Storage Temperature: -20oC to 60oC
Operating Temperature: 0oC to 45oC
Relative Humidity:
20 to 95% non-condensing
System Power: 220 VAC (±10%) 50±3HZ
Power wastage: 1.0 KW (Max)
Noise<55DB
X-RAY Sensor: L-shaped array detector, 24bit,Single energy
CERTIFICATIONS:
