Dredger pipe

Specifications

UHMWPE Dredger Pipe:

Company: Shandong Buoy&Pipe Industry Co., Ltd.

Main Products:  UHMWPE (Ultra high molecular weight polythene) pipe

wear resistant UHMWPE slurry dredge pipeline, Slurry Dredging Pipes, Sand Dredging Pipes,

Slurry Discharging Pipes, Sand and Sediments Discharging Pipes, Suction Dredging Pipes,

Floating Pipeline, Floating Dredging Pipeline,  Offshore Dredging Pipeline,

Sand and Gravel Dredging Pipeline, Mining Dredging Pipes, Mining Discharging Pipes,

Coal Slurry Discharging Pipes, UHMWPE Conveyor Roller

Business type: manufacturer and exporter

OEM service: Available

Specification: DN77-DN1200

            WT: 6mm-50mm

            Length: 1m-12m

Q: What is UHMWPE?

 A: Ultra-high molecular weight polyethylene (UHMWPE) is a new kind of engineering thermoplastics with more than 3 million viscosity-average molecular weight. Ultra-high molecular weight polyethylene pipe has superior performance over conventional HDPE pipe such as very high wear resistance, impact resistance, excellent resistance to internal pressure strength, resistance to environmental stress cracking, intrinsically self-lubricating, anti-adhesion, low temperature resistance and excellent chemical resistance.

Q: Why should you use UHMWPE Dredge pipes?

 A: Because it will save your time and money!

 Q: How can UHMWPE pipes do this?

 A:UHMWPE Piping Advantages:

Q: Why should you choose Shandong Buoy&Pipe Industry Co.,Ltd

A: a)Professional: we have more than 10 years experiences in UHMWPE field, with professional R&D team, and technology team

     b) Increasing Production Capacity: with 25 production lines, annual production capacity could reach more than 20,000 metric tons, with various specifications ranging from 77mm to 1200mm, or customized.

    c) Honest: we are committed to supply the best UHMWPE pipes with 100% virgin material for customers.

Molecular Weight Comparison between UHMWPE&HDPE: The higher molecular weight, the better wear resistance .

Advantages of UHMWPE Pipes:

Longer Life

With a wear resistance 4 to 7 greater than Q235 Steel or 10 times that of HDPE (PE100) pipes under the same operating conditions, UHMWPE Pipe will give you far superior life under most operating conditions. UHMWPE is an inexpensive alternative to metals and ceramics

Non-Scaling

Because of its very smooth surface and self-lubricating properties, UHMWPE Pipe has far superior anti-scaling properties to any other pipeline on the market today. A non-stick factor that leads to its strength in the marine industry,  preventing barnacle formation.

Lower Maintenance Costs, Less Maintenance Time, Less Downtime, Less Loss of Production

The far superior collaboration of wear resistance and weight reduction (0.93 SG) means the time between pipe replacements and/or rotations can be increased whilst simultaneously reducing installation management constraints of lifting gear and excavation requirements.

Reduced Pumping Costs

Along with the benefits mentioned above, UHMWPE Pipes also offer significant cost savings through increased pumping efficiency. With a surface roughness of 0.00022mm UHMWPE Pipe is extremely smooth and has resultant properties superior to PTFE (Teflon). Quantifying by example UHMWPE has a friction coefficient of 0.05, compared to 0.28 for HDPE or 0.58 for Steel (ISO 8295). This means less friction, less pressure loss and greatly reduced energy inputs to deliver the same result.

Lower Installation Costs

UHMW PE Pipe is connected by flanges and fastened by bolts and nuts.It has merits of quick connection,easy to dismantle,high strength,good tightness,etc.There is no need to do corrosion proof and rare trouble spots in the pipeline.It saves a lot of installation and maintenance cost and increases benefits.

Lower Maintenance Costs

The superior wear resistance enables the UHMWPE pipes to have longer service life than steel pipes, and effectively reduce the rollover times for the UHMWPE pipelines, which minimize the maintenance costs for the project.

UHMWPE Pipe Specification:

UHMWPE Pipeline Images:

 Packaging: by poly bag or wooden box according to customer requirement

Shipping: by sea or by air

   Customer service:

  Any questions to be sent will get response within 2 hours.

Lead Time:

Sample Lead-times: generally 7 workdays.

Production Lead-times: 35 workdays after getting your deposit.
