Ultra PE Pipeline for Offshore Dredging Project
- 10000 Meter / Meters per Month
- Qingdao Port
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | baoerpu | |
| Model Number | 77MM~1200MM | Material | Other, UHMWPE | |
| Specification | DN77~DN1200 | Length | 3M~12M | |
| Thickness | 6~50MM | Standard | ISO |
Product Description
Ultra PE Pipeline for Offshore Dredgine Project :
Workshop Image for Ultra PE Pipeline:
Company: Shandong Buoy&Pipe Industry Co.,Ltd
Business type: Manufacturer
Products: UHMWPE pipes&UHMWPE Navigation Aids
Employees: about 200 employees, professional R&D team, professional engineers& installation team
Production Lines: 25 lines, with annual production capacity of 10,000 metric tons
Ultra PE Pipes Sizes: inner diameter from 77mm to 1200mm, with different wall thickness, all the pipes can be customized according to the specified project.
Certificates:
Company Images:
1,High efficiency of Installation
Traditional wear resistant steel pipe is easy to corrosion, light in weight, and difficult to unload.However, HDPE wear resistant pipe is light in weight, flexible, easy to load and unload, transport, install and operate which greatly save transportation and installation cost.
2,Convenient and Quick Installation
Wear resistant HDPE pipe is connected by flanges and fastened by bolts and nuts. It has merits of quick connection, easy to dismantle, high strength, good tightness, etc. There is no need to do corrosion proof and rare trouble spots in the pipelines. It saves a lot of installation and maintenance cost and increases benefits.
3,Low Maintenance Cost
With extraordinary wear resistance, HDPE pipe has longer life than traditional steel pipe which effectively reduces times of rollover of pipelines, prolongs working life of the pipelines and lowers comprehensive construction cost of the project. Wear resistant HDPE pipe is adhesive resistant and difficult to scale which avoids acid cleaning used in steel pipe. Wear resistant HDPE pipe is corrosion resistant which avoids corrosion proof work during the project.
Diameter | Wall Thickness(mm) | |||||
0.6Mpa | 0.8 Mpa | 1.0 Mpa | 1.25 Mpa | 1.6 Mpa | 2.0 Mpa | |
150 | — | — | 7 | 8 | 11 | 14 |
200 | — | 7 | 9 | 11 | 14 | 18 |
250 | 8.4 | 10.6 | 12.9 | 15.7 | 19.9 | 24.7 |
300 | 9.7 | 12.3 | 15 | 18.5 | 23.4 | 29.3 |
350 | 9 | 12 | 15 | 19 | 25 | 32 |
400 | 10 | 14 | 17 | 22 | 29 | 36 |
450 | 12 | 16 | 20 | 25 | 32 | 41 |
500 | 13 | 17 | 22 | 27 | 36 | 45 |
550 | 14 | 19 | 24 | 30 | 39 | 50 |
600 | 15 | 21 | 26 | 33 | 43 | — |
650 | 17 | 22 | 28 | 36 | 46 | — |
700 | 18 | 24 | 30 | 38 | 50 | — |
750 | 19 | 26 | 33 | 41 | — | — |
800 | 21 | 28 | 35 | 44 | — | — |
850 | 22 | 29 | 37 | 47 | — | — |
900 | 23 | 31 | 39 | 49 | — | — |
1000 | 26 | 34 | 43 | — | — | — |
1100 | 28 | 38 | 48 | — | — | — |
1200 | 31 | 41 | — | — | — | — |
Q: Why should you use UHMWPE Dredge pipes?
A: Because it will save your time and money!
Q: How can UHMWPE pipes do this?
A:UHMWPE Piping Advantages:
Q: Why should you choose Shandong Buoy&Pipe Industry Co.,Ltd
A: a)Professional: we have more than 10 years experiences in UHMWPE field, with professional R&D team, and technology team
b) Increasing Production Capacity: with 25 production lines, annual production capacity could reach more than 20,000 metric tons, with various specifications ranging from 77mm to 1200mm, or customized.
c) Honest: we are committed to supply the best UHMWPE pipes with 100% virgin material for customers.
Contact Us
- Shandong Buoy & Pipe Industry Co., Ltd.
- Contact nameClare Zhang Chat Now
- Phone86-0635-5085878
- AddressNo.36 Huanghe Road Economic Development Zone, Liaocheng, Shandong
