Security and Protection-----walk Through Metal Detectors XYT2101LCD

Security and Protection-----walk Through Metal Detectors XYT2101LCD thumbnail-1
Security and Protection-----walk Through Metal Detectors XYT2101LCD photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Guard Spirit
Model Number:
XYT2101LCD
Contact Supplier Request Quote Chat Now
Shenzhen Xinyuantong Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Guard Spirit
Model Number XYT2101LCD



MODEL:XYT2101--LCD (8-24 zones,waterproof)



Technical parameter



Electric current: AC85V~264V/47-63HZ,24-28W

Workplace environment: -20°C~+55°C

Humidity:0 to 95%, no condensation

Battery:12 VDC

Standard: CE,ISO

Door panel size: 2230*560*82 mm

Control unit case size: 700*380*180 mm

Outer size:2234*835*580mm

Inner size:2000*700*500mm

Panel Material:Wood & PVC

Net weight:65KG

The volume weight: 90Kgs

Volume: 0.60CBM



Characteristic & Function

  • 5.7 inch LCD screen with Infrared remoter controller
  • Adopt advanced digital signal processing control replaced traditional analog signal control, better stability.
  • Friendly windows interface, English program, easy to operate.
  • Program Self-diagnostic when power on, automatically checking left and right door panel, LED light and choose the best working frequency.
  • Automatically count passengers and alarm times, keep alarm records for inquiry (up to 20000 records)
  • Detecting Zones: Standard 8 zones. It can extend to 16,24 zones by separate left and right alarm
  • Sensitivity adjustable: Each zone has 255 degree sensitivity level, three patterns: High, middle, Low for different requirements. Preset the metal size, weight, volume, location to exclude the coin, key, belt..
  • Sound Alarm: 1-25s alarm time, 255 different sound volume and 12 tones for choose
  • LED light alarm: LED bar graph on left and right door frame, visible alarm simultaneously to ascertain the layout of metal articles
  • Lock and Password protection, only the authorized person can operate.
  • Anti-interference function, using advanced interactive transmitting and receiving to avoid interference, frequency range from 4K-8K to avoid frequency interference
  • 6 preset programs for security application versatility
  • PVC material and Control unit on the top, waterproof, moisture-proof and cooler.
  • Integrated and modularized circuit design lead to simple installation and more convenient after services.
  • Adjustable Passing speed: up to 100 persons/min
  • Background light: 0-99 seconds for choose
  • Calendar function: real time display year, month, date, hour, minute, second
  • Harmless to heart peacemaker, pregnant women, magnetic floppy, recording tapes, etc.
  • Network support: (For Option)


Application

Walk through metal detector XYT2101LCD is popular used in Airport, banks, Embassies, Jail, Entertainment places, Gymnasiums, Exhibition Center ..etc
