What is the Features of the Floatless Relays ?
• Easy maintenance with building-block Relay Units.
• Easy identification of operating status with LED operation
indicator.
• Lineup includes models for tropical regions and for high
temperatures. Achieve stable detection even in hightemperature environments.
What is the Specifications about our Floatless Relays ?
| lassification | Floatless Level Switch Relay | |
| Specification Model | 61F-GP-N | |
| Dimension (mm) | 50H × 40W × 70D | |
| Socket Type | PF113A(E) | |
| Sensing Mode | General | - |
| High Sensing | - | |
| Long Distance | - | |
| Low Density | - | |
| Two Lines | 61F-GP-N | |
| Rated Voltage | AC: 110V, 220V, 240 50/60Hz | |
| Indicator Operating | Two LED's use for two status | |
| Operate Voltage | 85~110% of rated voltage | |
| Second Voltage | 8VAC (except high sensing 24VAC) | |
| Operate Resistance | 4K ohm min.(GENERAL) | |
| Release Resistance | 15K ohm min.(GENERAL) | |
| Response Time | Operate: 80msec max, Release: 160 msec max. | |
| Contact Rating | 5A, 250VAC(RESISTIVE LOAD) | |
| Length of Cable | 1Km max.(GENERAL) | |
| Life | Mechanical | 5 × 106 times min |
| Electrical | 105 times min | |
| Insulation Resistance | 100Mohm (DC 500V)min | |
| Dielectric Strength | 1500VAC, 50/60Hz, for 1 minute | |
| Consumed Power | 3.2VA | |
| Ambient Temperature | -10oC~+55oC | |
| Ambient Humidity | 45~85%RH | |
| Weight | 150g | |
What is the packing for our product?
What is the delivery way?
(1)If ship by sea and Air,you can get Bill of Loading,CO,Commerical invoice,Packing list from us after ship.
(2)If ship by express company,you will get a Tracking No. from us after ship.
What the Certifications do we have obtained?
What is the payment?
What's the Refund & Replacement?
1. 90-day-warranty.
If there is any quality problem (defective / don't work) of the goods, it could be returned within the warranty days. (Please notify us as soon as possible)
2. Any items must be returned in their original condition to qualify for a refund or replacement. (Any used items cannot be refunded or replaced).
Company view
Our team
What is the MOQ of our Floatless Relays?
MOQ: We support sample order.(1~5PCS)
More than 500PCS,can pring Logo on the products.
How to Visit and contact us?
Firstly, you are highly welcomed to visit our factory, we can provide you an invitation letter from Chinese Embassy for you if needed.
Besides, we are more pleased to help you to book a flight or hotel to save your time.
