Help CenterG35 Series 10-30VDC/90-250VAC NPN/PNP/2 Wires With NO/NC/NO+NC Output Infrared Photoelectric Sensor , Photoelectric Switches
Related Products
-
G36 Series 10-30VDC/90-250VAC NPN/PNP/2 Wires With NO/NC/NO+NC Output Infrared Capacitance Photoelectric Sensor SwitchesUS$ 9.9 - 17.6MOQ: 10 Pieces -
G40 Series 10-30VDC/90-250VAC NPN/PNP/2 Wires With NO/NC/NO+NC Output Infrared Capacitance Photoelectric Sensor SwitchesUS$ 7.7 - 14.3MOQ: 10 Pieces
-
G44 Series 10-30VDC/90-250VAC NPN/PNP/2 Wires With NO/NC/NO+NC Output Infrared Capacitance Photoelectric Sensor SwitchesUS$ 9.9 - 18.7MOQ: 10 Pieces
-
G50 Series 10-30VDC/90-250VAC 2 Wires Output Infrared* Photoelectric Sensor Switch/ Quality ChoiceUS$ 5.5 - 9.24MOQ: 10 Pieces
-
G54 Series 10-30VDC/90-250VAC NPN/PNP/2 Wires With NO/NC/NO+NC Output Infrared Capacitance Photoelectric Sensor SwitchesUS$ 7.7 - 14.3MOQ: 10 Pieces
Main features:
2 . high precision of repeated location
3 . Diversified exterior structures
4 . Good performance of anti-interference
5 . Many output forms
6 . High on-off frequency
7 . Dust proof,vibration proof,water proof and oil proof.
8 . With short-circuit protection and inverted connecting protection.
9 . Long service life
| Diffuse type | Detection distance | 50cm | ||
| 10-30VDC | NPN | NO | G35-3A50NA | |
| NC | G35-3A50NB | |||
| NO+NC | G35-3A50NC | |||
| PNP | NO | G35-3A50PA | ||
| 90-250VAC | NC | G35-3A50PB | ||
| NO+NC | G35-3A50PC | |||
| SCR Contro Hable silicon | NO | G35-2A50LA | ||
| NC | G35-2A50LB | |||
| Relay output | G35-2A50JC | |||
| Retroreflective type | Detection distance | 3m | ||
| 10-30VDC | NPN | NO | G35-3B3NA | |
| NC | G35-3B3NB | |||
| NO+NC | G35-3B3NC | |||
| PNP | NO | G35-3B3PA | ||
| 90-250VAC | NC | G35-3B3PB | ||
| NO+NC | G35-3B3PC | |||
| SCR Contro Hable silicon | NO | G35-2B3LA | ||
| NC | G35-2B3LB | |||
| Relay output | G35-2B3JC | |||
| Through beam | Detection distance | 5m | ||
| 10-30VDC | NPN | NO | G35-3C5NA | |
| NC | G35-3C5NB | |||
| NO+NC | G35-3C5NC | |||
| PNP | NO | G35-3C5PA | ||
| 90-250VAC | NC | G35-3C5PB | ||
| NO+NC | G35-3C5PC | |||
| SCR Contro Hable silicon | NO | G35-2C5LA | ||
| NC | G35-2C5LB | |||
| Relay output | G35-2C5JC | |||
| DC/SCR Control output | DC:200mA | |||
| DC/AC Consumption current | DC<15mA,AC<10mA | |||
| DC/AC Response time | AC/Dc<2ms | |||
| Directional angle | 3 . -10 . | |||
| Detected object | transparent or opaque body | |||
| Working environment temperature | 25~+55ºC | |||
| Intensity of illumination of working environment | Sunlight under 1000LX incandescent lamp under 3000LX | |||
